Product Description
Features : "This upgrade Version WPS Wireless-N Repeater is mainly used for providing free WiFi service at your home and office etc. Want to see your favorite online TV Show but the TV is on the dead zone? Your long and old house cut your video call with your friends? The bell can not work because it can not receive wifi? Now, say goodbye to dead zone with this MakeTheOne wifi repeater.Enough of no wifi!"
Application : Setting up a Wireless Infrastructure Network , For a typical wireless setup at home (as shown below) , please do the following :
Wireless Repeater Mode : You will need WiFi AP/Router internet access ,plug the wifi extender to a power slot , after configuration to be an access point
Wireless ap Mode : You will need broadband Router internet access , Connect the wifi repeater to your router/switch with RJ-45 Cable
Color : Polish White
Frequency range : 2.4-2.4835GHz
Wireless transmit power : 14 ~17 dBm (Typical)
Power supply unit : 100V-240V AC
Wireless Signal Rates With Automatic Fallback
11n : Up to 300Mbps(dynamic) ; 11g : Up to 54Mbps(dynamic) ; 11g : Up to 11Mbps(dynamic)
Modulation Technology : DBPSK , DQPSK , CCK , OFDM , 16-QAM , 64-QAM
Receiver Sensitivity 300M : -68dBm@10% PER 11M : -85dBm@8% PER
150M : -68dBm@10% PER 6M : -88dBm@10% PER
108M : -68dBm@10% PER 1M : -90dBm@8% PER
54M : -68dBm@10% PER
Package Includes : 1 x Wireless Wifi Extender Repeater
1 x RJ-45 networking cable(1 Meter length)
1 x user manual
Feature
【Easy for Installation】The WiFi extender supports WPS function (connect your router through pressing the buttons of the repeater and router alone). Extending the wireless coverage in all WLAN networks;
【Maximum 300Mbps】The WiFi booster complies with IEEE 802.11b, IEEE 802.11g, IEEE 802.11n standards;Providing up to 300Mbps transmission rates;
【Universal 2.4Ghz Band】It Can work with any standard routher or gateway. 2.4 Ghz band means this signal range amplifier can support most of devices which can support wifi;
【Multiple Encryption Modes】The repeater supports WPA2 PSK/ WPA PSK/ WEP, which could protect your network well.The WEP mode can support outdated devices;
【Repeater and AP Mode】Support Wireless Repeater Mode and Standard AP Mode; One 10/100Mbps fast Auto-Negotiation Ethernet LAN port.
Brand : Maketheone
Item model num : CNE0241120
MPN(PartNumber) : RJ-45
EAN : 0753940957230
Product Dimensions(LxWxH) : 19x13x7cm ; 0 g
Package Dimensions(LxWxH) : 19x13x7cm ; 0 g
