Description:
This is a Audio kit. It is a replacement of CD changer. It can be easily installed and used. The installation and usage are the same as CD changer\'s installation and usage. Simply plug in for i pod for i phone or android with 3.5mm jack， you can play audio through car audio system and enjoy music in your car.

Feature:
1.Direct connection via CD changer Port with CD quality sound.
2.Control music files from your car radio panel or steering wheel.
3.Building in high quality MP3/WMA decoder.
4.Building in Amplifier chips.
5.No signal interfere， No battery required.
6.Smart design and easy to install and use.
7.Support external source like like: MP3-Player， Portable DVD-Player， Mini Disk-Player， Notebook/Tablet， for psp，for most smartphone.

Specification:
Voltage input: 12V DC
Signal-to-noise: 95DB
Max. current: 600MA
Max. voltage output: 12V
D/A Device: 24BIT 192KHZ
Total Harmonic distortion: 0.01%
Frequency Response: 20HZ-20KHZ
Working Temperature: -10℃ - 80℃

Compatible with for honda Vehicles:
- for Accord 2003-2011
- for civic 2006-2010，
- CRV 2004-2011，
- for element 2003-2011，
- for odyssey 2005-2010，
- for pilot 2005-2011，
- Fit 2006-2011，
- for S2000 2005-2010

Installation Instruction:
1. Turn off car engine and remove key from ignition， if your radio use a security code，
make sure that you have the code before unplugging the radio.
2. Unmount the radio from the dash and find CD changer port at the back of radio.
3. Plug the for i pod AUX Adapter connector to CD changer port.(For Audi/V.W/Skoda/Seat radio，connect the GND cable to the shield of the radio)
4. For for i pod/for i phone user，connector for i pod/for i phone via for i pod AUX Adapter 30P connector.once the unit is installed just power on the car radio and for i pod，you can Press CD button，then you can enjoy the for i pod Music ，keep for i pod changed and ready to go.
5. For Auxiliary device such as for psp，MD.MP3.mobile etc，connect it with 3.3 Jack cable. It will start play music.

Package Included:
1 x Car for honda Music Interface
