功能描述：



适用于各种家用50G，75G纯水机。



产品基本参数：



材质：塑料（底座钢支架） 功能：增压



原理：隔膜泵 泵轴位置：卧式



驱动方式：电动 叶轮数目：单级



叶轮结构：敞开式叶轮 叶轮吸入方式：单吸



式



工作电压：DC24V 工作电流：0.65A



工作压力：80PSI 极限压力：125PSI



工作流量：0.6LPM 水泵接头行业标准：4046





（3/8螺纹，1/4管径）





产品重量:1.8KG，毛重2KG 机器尺寸约：长17CM*直



径8CM



优点：采用国际领先的专利密封技术和控制，解决增压泵



因工作时间过长而导致漏水或压力不足问题，超高进水压



力检测，杜绝区域水压不同造成漏水现象；超静音设计、



震动小、噪音低，听觉控制在1米内；专利技术设计，在



相同功率条件下，水泵流量更大，纯水机产水量及稳定性



更佳。
Functional Description:



Applicable to all kinds of home 50G, 75G water machine.



Product basic parameters:



Material: plastic (base steel bracket) Function: pressurized



Principle: diaphragm pump shaft position: horizontal



Drive mode: electric impeller number: single stage



Impeller structure: open impeller impeller Inhalation: single suction



formula



Operating voltage: DC24V Operating current: 0.65A



Working pressure: 80PSI limit pressure: 125PSI



Working flow: 0.6LPM water pump connector industry standard: 4046





(3/8 thread, 1/4 diameter)





Product weight: 1.8KG, gross weight 2KG Machine size about: long 17CM * straight



Diameter 8CM



Advantages: the use of international leading patent sealing technology and control, to solve the booster pump



Due to too long working hours lead to leakage or lack of pressure, high water pressure



Force detection, to prevent the regional water pressure caused by different water leakage phenomenon; ultra-quiet design,



Vibration small, low noise, hearing control in 1 meter; patented technology design, in



The same power conditions, the pump flow is greater, pure water machine water production and stability



Better.a
