Aircraft
Weight (with battery and propeller): 1280 g
Diagonal distance (with paddle): 590 mm
The maximum rise speed: 5m / s
Maximum lowering speed: 3m / s
Hovering accuracy: Vertical: ± 0.1 m (within the operating range of the ultrasonic); ± 0.5 m
Level: ± 1.5 m
The maximum level flight speed: 16m / s (under ATTI mode, no wind environment near sea level)
Maximum flight altitude: 6000m
Working temperature: 0 ℃ to 40 ℃
GPS module: GPS / GLONASS dual-mode
PTZ
Controlled rotation range: -90 ° tilt to + 30 °
Stabilization system: 3- axis (pitch, roll, yaw)
camera
Camera sensor: 1 / 2.3 inch CMOS, 12.4 million effective pixels (total pixels 12,760,000)
Lens: FOV90 ° 20mm (35mm format equivalent) f / 2.8, the focus infinity
ISO range: 100-3200 (video), 100-1600 (photo)
Electronic Shutter speed: 8 seconds 1/8000 sec
Photo Maximum resolution: 4000 * 3000
Photo Shooting mode: single shot
Multi Burst (BURST): 3/5/7 Zhang
Auto Exposure Bracketing (AEB): 3/5 sheets
@ 0.7EV step
Time Lapse
Video Resolution: phantom 3 professional: UHD: 4096 * 2160p 24 / 25,3840 * 2160p 24/25/30
FHD: 1920 * 1080p 24/25/30/48/50/60
HD: 1280 * 720p 24/25/30/48/50/60
phantom 3 advanced: 2.7k: 2704 * 1520p 30 (29.997)
FHD: 1920 * 1080p 24/25/30/48/50/60
HD: 1280 * 720p 24/25/30/48/50/60
Support document storage formats: File system: FAT32 / exFAT
Image formats: JPEG, DNG
Video format: MP4 / MOV (MPEG-4AV / H.264)
Support card type: Micro SD card, maximum support 65GB capacity, transmission speed of Class 10 and over or reach UHS-1 rating of micro SD card
Video storage largest stream: phantom 3 professional: 60Mbps
phantom 3 advanced: 40Mbps
Working temperature: 0 ℃ to 40 ℃
Visual positioning system: Speed measuring range: flight speed of less than 8 m / sec (2 meters height, adequate lighting)
Height measuring range: 30-300 cm
Use of the environment: the ground is rich in texture, light conditions sufficient (> 15lux, normal indoor fluorescent illumination environment)
WiFi: Operating frequency: 2.400GHz-2.483GHz
Signal maximum effective distance: FCC1000 meters, CE: 500 meters (outdoor open unobstructed environment, flight altitude 120 m)
Transmit power (EIRP): FCC: 27dBm; CE: 20dBm
Remote control: Operating Frequency: 2.400GHz-2.483GHz
Signal maximum effective distance: 5000 meters (without interference, without shelter, FCC modes)
3500 meters (without interference, without shelter, CE mode)
Video output interface: USB
Working temperature: 0 ℃ -40 ℃
Battery: 6000mAh rechargeable lithium battery 2S
Mobile equipment rack: Suitable for Tablet PC or mobile phone
Receiving sensitivity (1% per): - 101dBm ± 2dBm
Equivalent isotropic radiated power (EIRP): FCC: 20dBm; CE: 16dBm
Operating current / voltage: 1.2A / 7.4V
Charging Interface: Micro USB
Charger: Voltage: 17.4V
Rated power: phantom 3 professional: 100 watts
phantom 3 advanced: 40 watts
Intelligent Vehicle Battery (PH3-4480mAh-15.2V): Capacity: 4480mAh
Voltage: 15.2V
Battery type: LiPo 4S
Energy: 68Wh
Battery overall weight: 365 g
Working temperature: -10 ℃ to 40 ℃
Flying time: about 23 minutes
The maximum charging power: 100 W
APP / image transmission: mobile device APP: DJI GO
Effective isotropic radiated power: 100mW
Power Spectral Density: 6.9mW / MHz
Operating Frequency: 2.4GHz ISM
Real-time image transmission: 720P @ 30fps (depending on the actual shooting environment and mobile devices)
Delay: 220ms (depending on the actual shooting environment and mobile devices)
Mobile equipment system version requirements: iOS8.0 or later
Android 4.1.2 or later
