Item Descriptions:

Easy to use!

!

● Power on

When the headphones are off, press and hold the power button for 2 seconds.

The LED flashes blue and you hear "Power on" sound.

Then it blinks blue every second.

● Pairing with a wireless device

When the headphones are on, press and hold the power button for about 4 seconds until the LED alternately flashes blue and red, then select "AUSDOM AH 3" to pair.

1. The blue LED lights up in combination with the SBC device.

2. The blue and red LEDs will light up in combination with the APTX device.

3. When pairing with the APTX-LL device, the blue and green LEDs will light up.

● Power off

When headphones are on, press and hold the power button for 2 seconds.

The LED flashes red and you hear the voice "Power off".

Increase the volume: Press the volume up (V +) button.

Decrease the volume: Press the Volume Down (V-) button.

Play media: press power button

Pause / resume media playback: Press the power button

Skip to the next song: While holding down the V + button for 2S

Skip to the previous song: While holding down the V - button for 2S

To answer a call

When the phone arrives, the LED flashes red twice every second.

Press the power button to answer the phone.

The LED flashes blue twice every second.

Hang up: Press the power button

Base sound effect:

When playing music, press the power button twice to start the bass effect, then press the power button twice to return.

Caution:

When the volume reaches the minimum or maximum, an alert sounds.

Turning on the unit to play music will default to the last sound effect.

【Adoption of apt-X low latency technology】

Supported codecs support "aptX Low Latency" of ultra low delay technology in addition to SBC, aptX, this technique improves the export speed of audio frequency (extending within 40 milliseconds), the sound from the headphones is

It will be in sync.

Even when using movies and games, minimize the gap between audio and video and realize comfortable wireless playback.

apt - X low latency technology?

aptX was born at the Queen's University in Belfers, England in 1990 as a broadband stereo low-latency codec algorithm based on ADPCM academic research.

Originally adopted in broadcasting industry and professional audio equipment, it is also adopted in 5.1 ch technology of DTS company which appeared in 1993.

"AptX Low Latency" is the latest highlight of aptX which realized low delay of 40 ms or less which enables transmission with low delay.

aptX Low Latency is the latest codec that keep latency below 40 ms.

Especially low latency is realized when the latency of the other Bluetooth codec is 70 ms (± 10 ms) at the normal aptX, 120 ms (± 30 ms) at the AAC (128 mbps), 220 ms (± 50 ms) at the SBC

[Bluetooth 4.2]

With bluetooth 4.2 CSR chip, it can communicate with wireless compatible device up to 10 meters.

【Wireless high sound quality】

Enclosed dynamic headphones equipped with a 40 mm driver unit enable wireless playback via Bluetooth, enjoying favorite songs rich and clear sound.

【Comfortable fitting feeling】

By adopting AUSDOM company's standard wearing comfort, based on ergonomics, by adopting a high-grade leather - the ear pad gives a soft feeling to people, even if wearing glasses for a long time, there is a feeling of pressure even when wearing eyeglasses

And there is no pain.

【Continuous playback possible for a long time】

Wireless headphones are also capable of holding batteries for about 16 hours, so once you charge it, there is nothing to worry about that day.

[Wired usable]

Even if the battery runs out when there is no charging environment, it can be used with the included 3.5 mm audio cable.

【Acquisition of technical special mark】

Please do not worry because we have got a special technique mark.

Unique merit:

● apt-X low latency technology adoption (extension within 40 milliseconds)

● Built-in noise canceling function

● Using a large 40 mm driver

● Technically certified certified: with technical marking

● CSR Bluetooth 4.2

● Wireless & wired dual use

● Handsfree call

● NFC installed

● Lightweight stereo & comfortable fit

● Folding type

● 1 year security warranty

● With Japanese instruction manual

Product Specifications:

● Wireless specifications:

Wireless Version: 4.2

Transmission frequency: 2.402 GHz - 2.48 GHz

Corresponding profile: HSP / HFP / A2DP / AVRCP

Transmission format: SBC, apt-X, apt-X Low latency

Pairing name: AUSDOM AH 3

Battery specifications:

Battery type: Built-in 400 mah rechargeable lithium battery

Charge port: Micro USB 5V / 1A

Operating time: Music reproduction about 20 hours

Standby time: 2000 hours or more

Charging time: about 2 hours

Operating temperature: -10 ̊ C - 45 ̊ C

Storage temperature: -25 ̊ C - 60 ̊ C

Product Specifications:

● Microphone specifications:

Microphone unit: 4 * 1.5 mm

Directivity: omnidirectional

S.P.L: -42 ± 3 dB

Impedance: ≤ 2.2 KΩ

Frequency response: 100 Hz - 10,000 Hz

Operating voltage: 1-10V

● Speaker specifications:

Speaker diameter: Φ 40 mm

Impedance: 32 Ω

S.P.L: 95 dB

Total harmonic distortion: <3%

Frequency response: 20 Hz - 20,000 Hz

Package contents:

AUSDOM wireless headphones x 1

Micro USB charging cable x 1

3.5 mm audio cable x 1

User manual x 1 (including Japanese)

● One year warranty

Features:

• Please enter model number Confirm this is compatible:
• 【Adopted apt-X low latency technology】 With hermetically-sealed Bluetooth headphones, synchronize the sound and video from the headphones, minimizing the gap between audio and video (within 40 milliseconds) even when using movies and games,
• Apt-x Low Latency for Achieving Wireless Playback AUSDOM Wireless Headphone with NFC has been introduced.
• If you are watching sports on a smartphone or tablet, for example, ordinary Bluetooth headphones tend to get worried about delays, but if you are an Apt-x LL compliant device you can enjoy it without delay.
• 【Bluetooth 4.2 & high sound quality】 AUSDOM wired headset can communicate with wireless compatible device even up to 10 meters by adopting bluetooth 4.2 CSR chip.
• Enclosed type dynamic headphones equipped with a 40 mm driver unit make it easy to listen to wireless playback at the time of listening to trains, aircraft, etc., in various noisy and crowded environments such as running noise, no noise due to Bluetooth connection, no sound skipping
• Realization, you can enjoy favorite songs rich and clear sound quality.
• [Comfortable wearing feeling] By adopting a high-grade leather - based on ergonomics, the ear pad gives a soft feel, side pressure approaches the body moderately The head and the surroundings are not strange as well.
• Even when wearing glasses for a long time, there is little sense of oppression even when wearing eyeglasses attached, but because it has become a folding structure, it is a size it was a bit stuffy but you can carry it conveniently.
• [Wired and wireless use possible] In addition to being able to play for about 20 hours at maximum with a battery, it is also possible to use it with wired connection, so it is convenient to be able to use it according to the usage scene.
• Even if the battery runs out in an environment where there is no charging environment, it can be used as a wired type in case of emergency.
• 【One year warranty】 This product comes with a 12 month manufacturer's warranty after purchase and if there is any problem, please contact us and we will respond immediately.
• In addition, we will acquire the Technical Target mark, and Japanese instructions and warranty card will be attached so please use it with confidence.

Product information:

Shipping Weight: 449 g

Package Dimensions: 8.99 x 17.30 x 20.90 cm
