Power Output 1.23V-30V DC-DC Buck Converter Step Down Module LM2596

Specifications:

Module property:Non-isolation buck
Rectification mode:Non-synchronous rectifier
Input voltage:3V-40V
Output voltage:1.3V-35V
Output current:Rated current is 2A，maximum 3A(Additional heatsink is required)
Conversion efficiency:92%( highest )
Switching frequency:65KHz
Output ripple:30mV( maximum )
Load regulation:±0.5%
Voltage regulation:± 2.5%
Work temperature:-Minus 40 degrees - 85 degrees

dimension:43mm*21mm*14mm(L*W*G)

NOTE:This can\'t be used to step up Voltage

Package Include:

1 x Step Down Module LM2596
