One， overview

Rise up to Jin Chi PXN-V66 force feedback cable wheel is designed to complement the PC host computer and design， and can be used in PLAYSTATION3， PLAY STATION2 host. The wheel is compatible with PC， PS2， PS3 variety of force feedback games， but also for all the racing game does not support force feedback. Steering wheel with a programming function， technical feedback advanced gear technology and capacity， can provide a variety ofdetailed realistic game player force for different feedback effect， can make thegame player to find the true feeling of the car.

Two， function characteristics

1， support the work platform: PC， PLAY STATION2， PLAY STATION3;

2， support force feedback:

PC platform: NFS*， F1 series of force feedback.

PS2 platform: GT3， GT4;

PS3 platform: GT5;

At the same time also applies to all racing game does not support force feedback;

3， with 9 programming buttons (left， right， foot oil， foot brake， gear lever (-/+/R)，L3， R3);

4， with three sensitivity adjustment;

5， the master IC working voltage 5V， current of less than 20mA;

Provide force feedback voltage 24V， current of less than 700mA;

6， the wheel has a 270 degree rotation angle;

By 7， the direction of the steering wheel to the photoelectric control in;

8， provides 4 key eight direction input:，， left， right and the 45 degree angle;

9， providing 13 buttons: X/1， in /3， △ /4， △ /4 (R)， - /2， R1/5， R2/7， R2/7 (+)，R3/12， L1/6， L2/8， L2/8 (-)， L3/11;

10， providing 3 function buttons: Start/10， Select/9， MODE;

11， the pedal and the left hand is equipped with spring acceleration controlbraking device， with the true feeling of driving.

A， functional description

1 key programming function (without this feature in the PS3 force feedbackmode)

1.1 with 9 programming buttons: the shift lever shift lever +， -， shift lever R， foot oil， foot brake， right， left， L3/11， R3/12;

1.2 programming source keys: /2 key /3 key box， circle， X /1， /4 L1/6， the triangle button， L2/8， R1/5， R2/7;

1.3 programming methods:

1， at the same time， press "SELECT/9+START/10" key 3S， programming the red LED lights;

2， press the red button is programming， LED flash;

3， according to the programming source button， red LED， programming is complete.

1.4 programming step cleaning method:

1， with humble Cong?? "SELECT/9+START/10" key to 3S， the red LED lights;

2， press the red button is programming， LED flash;

3， then press the programmed key， red LED， programming step removed.

1.5 programming all clearing method:

At the same time， press the "SELECT/9+START/10" key 3S the red LED lightsand keep 2S， until the red LED lights go out， all the programming keys to remove， restore default state.

The 2 direction sensitivity adjustment function

1， directional sensitivity (sensitivity) is divided into 3 sections: the adjustment ofhigh (HI)， (MID)， low (LO);

2， as shown below: will switch to a different location， the sensitivity ofcorresponding.
