ADVANTAGE
OF
TECHNOLOGY
Automatic work mode can track patient's respiratory condition automatically , and sensitively change airway pressure to fit patients need.
Auto On: With this feature, the device automatically initiates therapy when you begin breathing on the device.
Auto Off: With this feature, the device automatically discontinues therapy whenever the mask is removed.
A therapy that delivers CPAP therapy while automatically adjusting the pressure level to meet the patient's needs.
DC 24V powered and infrared controlled humidifier make user safe and comfortable. Patented anti-countercurrent water tank.
Reslex: Automatically reduce the treatment pressure when patient exhales, more comfortable.
Delay off: This will blow off the vapor left in the humidifier to avoid any damage to the device.
An audible alert will sound if the device is accidentally disconnected from power when it is delivering air. No alert message on the screen during a power failure.
Depending on the location of the region to choose a different setting, the machine will make the pressure compensation accordingly and automatically.
Compliance Data is encoded by iCode and it is easy to be transfered by smart phone iCode APP.
You can search and download it from Google play and APP store easily and conveniently.
4GB capacity of SD Card can fully record the patient's treatment information data. Large capacity, easy operation, more comprehensive information access.
APPEARANCE
Buttons & Details
User Button: These buttons can be used when entering various menus to change some of the RESmart Auto settings.
Humidifier Button: This button will control the optional heated humidifier’s output.
Prow Light: When the power is switched on, the machine works, the indicator light turns on.
Start/ Stop Button: Use this button to start / stop the airflow. DO NOT start the airflow until the circuit tubing is connected.
User Button: These buttons can be used when entering various menus to change some of the RESmart Auto settings.
Ramp Button: When the airflow is turned on, use this button to restart the ramp cycle.When the airflow is turned off, use this button to access the patient menu.
Water Outlet: The water inlet is in the bottom of the water storage tank.
Air Outlet : Pour a small amount of residual water outlet.
Patient Menu
|
|
Option
|
Description
|
|
Auto On
|
When the RESmart Auto is standby and wearing mask, your deep breath will start airflow automatically
|
|
Auto Off
|
When the mask is removed, the RESmart Auto will stop airflow automatically
|
|
Reslex
|
A therapy feature that provides pressure relief during exhalation.
|
|
Mask Type
|
Select the type of mask you are equipped with
|
|
iCode
|
Scan iCode, access to treatment data
|
|
Brightness
|
The brightness of the machine screen is adjustable
|
*Notice: The patient's menu will not cover all the machine functions and options, more settings included in doctor's menu.
Doctor Menu
|
|
Option
|
Description
|
|
Mode
|
CPAP,AUTO,Titrate
|
|
Treat P
|
Treat P is the lowest pressure device deliver for OSA
|
|
Max APAP
|
Max P is the largest pressure being set under Auto mode
|
|
Ramp P
|
Pressure being delivered while patients are awake
|
|
Init P
|
Initial treatment pressure when the machine is running
|
|
Sensitivity
|
Five levels for pressure rise due to collapse of upper airway
|
*Notice: We seriously recommend you to follow your doctor's clinical advise before changing settings.
Packing List
|
Main Device
&
Humidifier
|
Tubing
|
NM4 Nasal Mask
|
Filter
|
Power Cord
|
User Manual
|
Carrying Case
|
Bag Belt
|
*Notice: If you want to change mask model, please leave note on the order page.
FAQ
Q1: What kind of person needs this product, and it's mainly for what indications?
Sleep Apnea Syndrome (SAS) Presentation: Snoring , daytime sleepiness, impaired concentration, hypertension , morning headache , slow reaction time , decreased memory , decreased libido.
Q2: Does the machine suitable to use at home? Does it easy to operate?
Yes, it's designed for sleep home care therapy and ventilation. After refer user manual, it will be very easy to operate by End-User.
Q3: How to set the machine airway therapy pressure or how to choose the work mode, and change other parameters?
All the settings can be changed in Clinical Menu. (Enter Clinical Menu: When the machine running, please press middle button and right button, hold them for 5 seconds will into the Clinical Menu.)
Q4: Where can I download the analyze software, any software fee required?
Online documentation and software for your BMC products can be downloaded free of charge.
(1) Download website: en.bmc-medical.com
(2) Download Step: [Service] - [Document & Software] - [Therapy and Ventilation Devices]
(3) Ask AliExpress platform customer services to get free download account and password.
Q5: What is iCode function? How to use iCode phone app?
Software usually for doctor to analysis, but iCode shows basic using data for End-User, more convenient to know recent condition. iCode I is numbers, iCode II is QR picture.
Three ways to use iCode get machine data:
(1) Go to iCode website (bmc-icode.com) , then input machine serial number to get data.
More instructions in [Help] page which on the top of the iCode website.
(2) Stop running machine, press humidifier button on the left of the machine, will come out iCode I numbers. Then d ownload phone app called BMC+, open the phone app, type the iCode I numbers in the phone app to get data.
(3) Also can rotate middle button change iCode I numbers to iCode II QR picture, use phone app sweep QR picture on the machine screen, done !
Q6: Why should I buy from BMC?
Only because we love you.
Brand BMC means: Best Medicine is Care.
Family care , above all.
Q7: Protable smart home CPAP machine can be used with another medical equipment?
Yes, reasonable use with a variety of medical devices, novelty & special use enhance the health of the body!
Such as: sphygmomanometer, oximeter, oxygenerator, oxygen ventilator, electronic blood pressure meter, automatic heart rate monitor, first aid kit medical!
