Item Descriptions:

Product introduction

● Lightweight, compact body with various functions

- Equipped with "G mode (golf mode)" which displays the addition / subtraction distance reading gradient of the golf course besides measurement of straight distance, horizontal distance and height

● Equipped with short distance priority algorithm

● Continuous measurement can be performed for 8 seconds by keeping the button pressed

● Safe waterproof structure even in the case of sudden rain (Battery compartment is a drip-proof structure equivalent to JIS protection grade 1)

● Measurable distances are 4.5 to 550 m (5 to 600 yd.)

From Amazon

Display an indication of the distance to be hit by a course with undulation

ID Technology-equipped models

Sporty and compact body, equipped with ID Technology to read the gradient.

Not to mention the straight distance, grasp the difference in elevation to the target, aim at the points to be hit in the undulating course without hesitation.

With a body design pursuing light coloring and ease of use, you can use it more stylishly and more actively.

By installing ID Technology, G mode (golf mode) which displays the standard of the distance to be hit

Equipped with ID Technology to read the gradient of the course, it corresponds to "G mode" which displays the standard of the distance to be hit (addition / subtraction distance = horizontal distance ± height) based on height difference.

It is difficult to grasp the sense of distance, "launch" or "downhill" course, to make sure the selection of clubs.

Main features

Measurement is possible from 5 to 600 yds. (4.5 to 550 m)

※ 1

"G mode" which displays the standard of the distance to be hit with gradient is installed

"Distance priority switching system" that can be selected according to the condition of the target

※ 2

"Continuous function" which can continuously measure for about 8 seconds if you hold down the button

Regardless of the measurement distance, a constant and fast distance measurement response

6-fold high-performance finder with multilayer coating

Easy-to-peep large eyepiece diameter

Easy to find small targets, bright and wide field of view

High eye point design easy to see while wearing glasses

Equipped with LED illumination that makes it easier to view even in dark places

Waterproof / drip-proof structure that can be used with confidence even on rainy days

※ 3

* 1: The measurable distance may change depending on climatic conditions and target type.

* 2 = [Short-range priority mode / Long-distance priority mode] When measuring overlapped targets, from the obtained distance results, measure the closest distance in the short distance priority mode and the farthest distance in the long distance priority mode

It displays it as a result.

* 3: Due to raindrops, the distance to the target may not be measured properly.

Liquid crystal display in viewfinder

1. Distance display

2. Launch display

3. Downward display

4. Laser light irradiation mark

5. Short-range priority mark

6. Distance unit display (m / YD)

7. Laser light irradiation mark

8. Target mark

9. Height indication (straight distance in G mode)

10. Battery level indicator

Spec comparison table

COOLSHOT AS LCSAS

COOLSHOT

COOLSHOT 20

Measurement range

4.5 - 550 m (5-600 ds.)

10 - 550 m (11 - 600 yds.)

5- 500 m / 6-550 yds.

Display step

Linear distance (upper 4 digits): 0.5 m / yd. Unit

Linear distance (lower 3 digits): 1.0 m / yd. Unit

Horizontal distance / addition / subtraction distance (upper 4 digits): 0.2 m / yd. Unit

Height (lower 3 digits): 0.2 m / yd. Unit (less than ± 100 m / yds.)

1.0 m / yd. Unit (± 100 m / yds. Or more)

0.5 m / yd. Unit

1 m / yd. Unit

magnification

6 times

6 times

6 times

Objective lens effective system

21 mm

21 mm

20 mm

Real field of vision

7.5 °

7.5 °

6 °

Diameter of pupil

3.5 mm

3.5 mm

3.3 mm

Eye relief

18.3 mm

18.3 mm

16.7 mm

size

113 × 70 × 39 mm

111 × 70 × 40 mm

91 × ​​73 × 37 mm

weight

Approximately 175 g

Approximately 165 g

Approximately 125 g

Power supply

CR2 lithium battery × 1 (3 V DC) With auto power off function (about 8 seconds)

CR2 lithium battery × 1 (3 V DC) With auto power off function (about 8 seconds)

CR2 lithium battery × 1 (3 V DC)

Waterproof performance

Waterproof structure, battery room drip-proof structure

Waterproof structure, battery room drip-proof structure

Waterproof life

Features:

• Please enter model number Confirm this is compatible:
• LCSAS

Product information:

Shipping Weight: 580 g

Package Dimensions: 9.80 x 13.00 x 16.79 cm
