Item Descriptions:

【Major features】

· LED light loading: It can be used as a flashlight for nighttime or when shooting!

In case

· Actual chargeable: Can be charged to your iPhone or smartphone in fact!

In case

· Motion detection function: Automatically start recording & stop in response to surrounding movement!

In case

· Single recording function: It is possible to record only audio, just like a voice recorder!

In case

· Easy operation: Operate with one button.

· High image quality: High resolution is achieved with resolution of 1280 x 720 pixels for movie and 4032 x 3024 pix for still image

· Multi-function: Recording, shooting still pictures, recording, led light, motion detection, recording time setting, resolution setting, etc. are equipped.

· With LED light: Since it is equipped with LED light, it is possible to illuminate at night.

· Motion detection: Recorded when moving objects are detected, it is used as crime prevention.

· Large capacity mobile battery: Since it is equipped with a large capacity mobile battery, it can power not only small cameras but also various smart phones such as iPhone.

· MicroSD card: microSD supports up to 32GB.

(It is necessary to prepare separately)

Product specifications】

◆ Video recording: microSD / SDHC maximum 32GB ※ sold separately

◆ Movie resolution: 1920 × 1080pix ※ 4 size selectable: 320 * 240/640 * 480/1280 * 720/1920 * 1080

◆ Movie format: AVI

◆ Still image resolution: 4032 × 3024pix

◆ Still image format: JPEG

◆ Recording format: WAV

◆ Power supply: Built-in lithium battery

USB: 2.0

◆ Supported OS: Windows 2000 / XP / Vista / 7

◆ Accessories: main body · USB cable · charging cable · with adapter for Micro usb

Power on

When the [POWER] button is pressed and the pilot lamp 3 lights up, the main unit enters standby mode.

Note: Please insert the SD card before using.

Power off

Long press the [Power] button, the pilot lamp goes out and turns off the power.

Shooting still images

In pause lamp mode (pilot lamp 3 lights up) press [Power] button twice in succession (please keep 0.5 second interval between two successive presses) and [Pilot lamp 4] flashes once,

I will take one.

Also press the 【Power】 button twice in succession to take a picture.

After taking a picture, return to standby mode.

Note: Please keep 0.5 second interval while pressing 【Power】 button continuously.

Recording

When the pilot lamp 3 blinks three times and pauses, it starts recording when pushing the [power] button briefly in standby mode (pilot lamp 3 is lit).

When you press the [Power] button once again, save the recording and return to standby mode.

The main unit automatically saves data every 10 minutes.

recording

When pilot lamp 3 is lit and pilot lamp 4 is blinking, push [Power] button three times in standby mode (pilot lamp 3 is lit) and recording will be done.

Press the [Power] button again to save the data and stop recording.

Note: Please keep 0.5 second interval while pressing 【Power】 button continuously.

Playback

Please connect with the personal computer using the included USB cable.

Please note: Please note that it may take up to 20 seconds to recognize the main unit.

Motion detection

When the pilot lamp 3 and the pilot lamp 4 continue flashing at the same time by pushing the [power] button continuously four times in the standby mode (the pilot lamp 3 is lit), and the moving object is detected, the pilot lamp 3 turns off

, The pilot lamp 4 continues to blink and the main body starts recording.

Press the [Power] button once again to save the data and stop recording.

Automatically save data every minute.

Note: Please keep 0.5 second interval while pressing 【Power】 button continuously.

LED lighting

With the standby mode (pilot lamp 3 lit) press the [Power] button five times in succession to turn on the lamp.

Note: Please keep 0.5 second interval while pressing 【Power】 button continuously.

Recording time setting

With the power on, connect the unit to the computer using the USB cable.

A removable disk (temporary) is detected and timeset.txt in the root directory

Create a new text file named 2016.01.01 13:30:30, write the current time in Y format, save it in the TF card directory of the main unit with timeset.txt file name, then mount the PC mount

Release it.

In case of non-display 2016-07-01 01:01:01 Change N and Y to N.

charging

Charging to the main unit: Connect to the Ac adapter slot or the USB port of the personal computer using the supplied USB cable exclusively.

Charging: Pilot lamp 2 lights up

Full charge: Pilot lamp 2 turns off

Power supply to other equipment: Use the supplied USB cable to connect to "Power supply output (DC 5 V 1A)" or "L power supply output (DC 5 V 2 A)" to supply power.

Setting resolution

With the power on, connect it to the computer using the USB cable.

A removable disk (temporary) is detected and sizeset.txt in the root directory of the TF card

Create a new text file, enter a single number from 1 to 4 half-width alphabetical characters 1 to 4, save it, then restart the unit, the setting will be reflected.

Resolution varies depending on the number you entered.

1: 320 * 240

2: 640 * 480

3: 1280 * 720

4: 1920 * 1080

For example, after writing a half-width alphabet 4 in a newly created sizeset.txt text file and saving it in the directory of the main TF card, the video format becomes 1920 * 1080.

◆ Notes ◆

We will refuse all purchase applications for the purpose of using for voyeurism and other illegal acts.

We do not sell to anyone who has a purpose to use for voyeurism or other illegal acts.

Please stop using products for illegal voyeurism absolutely.

If you purchase a product secretly (hidden) that it is a voyeuristic purpose, we will consider your order as canceled and in some cases criminal charges with fraud charges etc.

Features:

• Please enter model number Confirm this is compatible:
• 【Easy operation】 Operate with one button.
• Recording, taking still pictures, recording, led light, motion detection, recording time setting, resolution setting, etc. are equipped.
• [High image quality] Resolution is movie "1280 × 720 pix", still image "4032 × 3024 pix"
• [Motion Detection Function Installed] Since it will record when detecting moving objects, it is used as crime prevention.
• [Power supply to smaho] Since we have not only a compact camera but also a built-in battery, we can supply power to various smartphones such as iPhone.
• [LED light loading] Two LED lights installed!
• It can also be used as a flashlight and can be conveniently used at night or when shooting as needed!

Product information:

Shipping Weight: 190 g

Package Dimensions: 3.71 x 9.70 x 14.30 cm
