Item Descriptions:

Product introduction

● Equipped with surge noise filter and line noise filter ● Equipped with polarity checker of power plug ● Long body of 290 mm or longer, power cable of 3 m ● Power supply to 13 devices with a maximum of 1490 W is possible ● (AV-

15 units) ● Three non-interlocking front panel power connectors ● Voltage display (AV-P250LUV, AV-P2800) ● Brightness adjustable LED light units (AV-P250LU, AV-P250LUV) ● Power supply

Equipped with supplyable USB connector (AV-P250LU, AV-P250LUV) Sequential function (AV-P250S, AV-P2800) that can be turned on sequentially ● Externally controllable by external control terminal (AV-P2800

) ● Up to 10 Daisy Chain Connections Available (AV-P2800) ● Emergency Broadcasting (AV-P2800)

From Amazon

Acoustic equipment is made high sound quality with a clean power supply.

Dedicated power distributor / conditioner in Japan.

Deeply

Expanding

Series lineup

Expanding

<Features>

■ Two types of noise filters supply clean power

The electricity that reaches the outlet shows that the noise mixes due to various factors, and when it is observed with the measuring instrument, it shows a different waveform from the original signal.

In audio equipment, the power supply noise adversely affects the sound quality.

In all models of the AV-P series, a line noise filter that eliminates many of these noises is installed, enabling clean supply of power.

In addition, a surge noise filter which prevents noise mixing due to sudden overcurrent such as lightning is also carried.

■ Load polarity checker to check if plug-in direction is correct

In Japan, one side of the power outlet is connected to the ground, although it is generally unknown.

In order to obtain a high quality power supply, it is necessary to connect the ground of the acoustic equipment and the earth on the outlet side exactly.

If the polarity checker installed in the AV-P series is not connected correctly to the ground side of the receptacle socket of the AV-P main unit, the lamp lights up and it can be easily judged whether the connection is correct, so it is higher

It is possible to easily build a quality power supply environment.

■ Long body of 290 mm or more easy to set, 3 m power cable

Expanding

The body length is designed to be more than 290 mm.

We investigated the depth of the body of general rackmount equipment and adopted a long body which makes it easy to connect the power cable when installing in the rack.

In addition, it adopts 3 m long cable, it can be installed even in large rack installation or even when the power supply is far.

■ Three non-interlocking front panel power connectors that enhance convenience after installation

During operation, it is necessary to secure additional power supply in various situations such as temporary connection of personal computer, carry-in equipment from outside, mobile phone and so on.

In this case three front panel power connectors are provided to provide high convenience.

Because it is non-interlocking type, it can be utilized according to situations without interlocking with power-on of the AV-P series main unit.

■ 15A circuit breaker installed, can be recovered by just pressing a button

15 A circuit breaker adopts a button type that can smoothly return after turning off the power supply.

■ Power switch with guard to prevent erroneous operation of the switch

If power is cut off due to collision or misoperation during operation, there is a possibility of serious damage to production work and events.

The AV - P series adopts a power switch with a guard to prevent these accidents.

<Function>

· Supplies a surge noise filter, line noise filter in the power supply section, and supplies clean power that cuts external noises

· UNSWITCHED (non-interlocked) receptacle on the front panel

· SWITCHED (interlocked) receptacle on the rear panel

· 15 A circuit breaker with return switch

· Power polarity checker for noise reduction

· 1U rack mount size

Features:

• Please enter model number Confirm this is compatible:
• [Accessory] Rack mount viscit, 3P - 2P conversion adapter, warranty card, instruction manual
• Two types of noise filters supply clean power
• A polarity checker is installed to check whether the insertion direction of the power plug is correct.
• Long body of 290 mm or more easy to set, 3 m power cable
• Three non-interlocking front panel power connectors that enhance convenience after installation

Product information:

Shipping Weight: 4368 g

Package Dimensions: 13.31 x 39.70 x 55.30 cm
