Product Description
Menu
-LiPo LiIon LiFe LiHv
--Charge
---Voltage, Capacity, Charge Current
---End Voltage
----LiPo: 3.8-4.3V/C, 4.2V Default
----LiIon: 3.8-4.3V/C, 4.1V Def.
----LiFe: 3.3-3.8V/C, 3.6V Def.
----LiHv: 3.85-4.4V/C, 4.35V Def.
---Charge Mode: Balance or No
--Discharge
---Voltage, Capacity, Current
---End Voltage:
----LiPo: 3.0-4.2V/C, 3.0V Def.
----LiIon: 3.0-4.1V/C, 3.0V Def.
----LiFe: 2.0-3.6V/C, 2.2V Def.
----LiPo: 3.15-4.35V/C, 3.15V Def.
--Storage Mode
---Voltage, Capacity, Current 0.1-5.0A
---End Voltage
----LiPo: 3.7-4.2V/C, 3.7V Def.
----LiIon: 3.6-4.1V/C, 3.6V Def.
----LiFe: 3.3-3.6V/C, 3.3V Def.
----LiHV: 3.85-4.35V/C, 3.85V Def.
-NiMH NiCd
--Charge
---Capacity, Current, Mode: Manual/Auto, Delta Peak: 5-25mV/C, 5 Def., Trickle: OFF or 50-200mA
--Discharge
---End Voltage: 0.1-24.0V, Capacity, Current
--Cycle
---Capacity, Charge Current, Discharge Current, Discharge End Voltage: 0.1-24.0V, Cycle Mode, No. of Cycles: 1-5x, Delay Timer: 1-60Min
-Digital Power
--Voltage: 3.0-24.0V, Amperage: 0.1-10A, Max Power: 1-90Watts
-User Settings
--Precharge Time: OFF or 1-10Min, Temp Mode: C/F, Temp Cutoff, Input Power Low Voltage Cutoff, Safety Timer, Back Light, Full Charge Melody, Key Beep Buzzer Sound, User Name, Factory Reset
-Data View
--View
---Input Voltage, Output Voltage, Internal Temp, External Temp, Resistance, Cell voltages
--Balance
-Memory

AC Input: AC 100-120V OR 220-240V
DC Input: DC 11.0-18.0V
Charge current: 0.1-10.0A
Discharge current: 0.1-5.0A
Charge power: 100W ea
Discharge power: 12W ea
Balance current: 350mA
Balance tolerance: ±0.01V
Ni cells: 1-15cells
Lithium: LiPo LiIon LiFe LiHv
Lithium cells: 1-6Series
Pb: 2V-24V
mAh Capacity: 100-50,000mAh
Digital Power: 3V-24V
Weight: 1250g
Dimensions: 204x170x60mm
