Product Description

It may suitable for following models
K3: 2012/2013
Sportage R: 2010/2012/2014
Sorento: 2010/2012/2013
Borrego: 2008/2013
Carens: 2011
Opirus
Forte: 2014
Installation location: Car license plate light hole, keep your car original number plate lamp
Note: the car name we mentioned is based on data of China car and feedback from customers all over the world. According to our experience, the same brand car in different countries may have some differences, so please check the camera size and compare the installation of your car carefully to avoid mistake.
it supports after market head unit only. It should be with RCA yellow jack.
PAL is optional (Please leave message to us after finish the payment with in 24 hours)

Specifications
Lens materials: 100% Glass
Typical type: High-sensitivity mode for low-light conditions
Image Sensor: MT9V136
Wide Angle: 170 degree (Diagonal), 128 degree (Horizontal), 115 degree (Vertical)
Optical distortion: -88%
Video System: NTSC (default)
Image Output: 720H x 480V@NTSC, 720H x 582V@PALResolution: 480 TV Lines
Color filter array: RGB standard Bayer
Automatic functions: Exposure, white balance, black level offset correction and more
Degree of protection: IP67 (Waterproof)
Parking line: ON/OFF manual control
Trigger cable: Built-in
Image: Normal & Mirror manual control
Working time: Full-time continuous working (7*24Hours)
Power Supply: DC 5V to 28V
Working current: 67mA@DC 12V
Operating Temperature: -40oC to +80oC/-40oF to 176oF

Packing List
1pc Camera
1pc Power adaptor
1pc User manual
1pc 6m Video cable(RCA to RCA yellow Jack)

Function Control
If cut the white cable that on the camera, change the mirror image to normal image.
If cut the green cable that on the camera, cancel the parking line.

Feature

Support normal image & mirror image manual switch
Support guide line manual ON/OFF
Small size connector, easy for installation
Wide input voltage, DC 5V to 28V
100% copper video cable & glass lens
Brand : Generic
MPN(PartNumber) : CM1548-Kia-6
EAN : 0701385126735
