Product Description
BEIOU Downhill Dual Suspension 3K Carbon Fiber Mountain Bike Frame DW-LINK 26" Matte Black Unibody Internal Cable Routing T800 Ultralight 18" MTB B022A18X
MODEL: BO-B022A (26)
SKU: FMB022A18X
FINISH: 3K Matte Black
MATERIAL: Toray T800 Carbon Fiber M40
FRAME SIZE: 18"
WHEEL SIZE: 26"
BB TYPE: ENBB 68mm
CABLE ROUTING: Full Internal Cable Routing
TOP TUBE: 1-1/8, 1-1/2
HEADSET: BEIOU 41.8mm/52mm
BRAKE TYPE: Disc Brake
REAR SUSPENSION SIZE: 200mm
SEAT POST: 31.6mm
SEAT POST CLAMP: 34.9mm
REAR AXLE SPACING: 135mm
ACCESSORIES: Head set/Seat post clamp
WEIGHT: 2090g±50g
WARRANTY: 1 year
FEATURE:
BEIOU products were made mainly with Toray T800 carbon fiber, whose tensile strength is 500kgf/mm2, 4900MPa, the tensile modulus is 24ton/mm2, 230GPa, the elongation is 2.1, and the density is 1.8g/cm3.
For the part of Bottom Bracket, we overlap T800 and T1000 carbon fiber to increases the strength and the rigidity, which makes it work in great safety and speed up quickly in dancing.
The rear triangle part was made with Mitsubishi high carbon fiber, whose tensile strength is 450kgf/mm2, 4410MPa, the tensile modulus is 40ton/mm2, 395GPa, the elongation is 1.1, and the density is 1.82g/cm3.
