Item Descriptions:

· Be sure to read the instruction manual before using.

【Specification】 Equipment name · · · Ultrasonic atomizer.

Number of atomization units ... 1.

Vibrator drive frequency ... 1.6 MHz ± 50 KHz.

Transducer chemical treatment ... glass material.

Amount of atomization ... · 300 cc / h or more (water temperature · ambient temperature at 25 ° C).

Applicable floor area * · · Approximately 14 tatami (There is a possibility of increase / decrease depending on conditions).

Operating sound · · · 40 db or less.

Installation method ... stationary type.

Discharge port (fog outlet) ··· Horizontal direction 360 ° direction adjustable type (detachable type).

Water supply system ··· Tank type capacity 4.0 L (operation prevention function when tank is not installed).

Used liquid · · · Hypochlorous acid purified water (diluted HOCI below 80 ppm).

* Available only for Star-Giken designated products.

Feed water temperature ... 5 to 40 degrees.

Allowable ambient temperature · · · 5 to 37 degrees (freezing, no fogging).

Allowable Ambient Humidity ... 80% RH or less (No Spraying).

Rated voltage ··· AC 100 V (50/60 Hz).

Allowable voltage range ... 90 to 110% of rating.

Power consumption ··· 25 W.

Weight · · · about 2 kg when dried / about 6 kg when filled.

Outside dimension · · · 215 mm (W) × 320 mm [358 mm] (H) × 175 mm (D) * The inside of the brackets is attached with the spout.

· Power cord · · · with 2P plug cord 1.9 m.

· Other functions · · · · · · · · · · · · · · · · · · · · · · · · · · · ·

[How to use] <Operation> (1) Start driving.

(2) Adjust the amount of atomization.

<Put the liquid in the tank> (1) Remove the liquid tank from the main unit.

(2) Remove the outlet from the liquid tank.

(3) Remove the tank cap and put the liquid in the tank.

(4) Tighten the tank cap securely.

(5) Set the liquid tank in the main unit and attach the air outlet.

[How to use] <Operation> (1) Start driving.

(2) Adjust the amount of atomization.

<Put the liquid in the tank> (1) Remove the liquid tank from the main unit.

(2) Remove the outlet from the liquid tank.

(3) Remove the tank cap and put the liquid in the tank.

(4) Tighten the tank cap securely.

(5) Set the liquid tank in the main unit and attach the air outlet.

· Even though it is compact, it can be atomized all day with one water supply.

· Approximately larger than the appearance! Approximately 4L liquid tank entering plenty! · Since the volume to adjust the amount of fog generation is infinite, fine adjustment is possible depending on the situation you use.

· Ultrasonic nebulizer SX-100 makes hypochlorous acid water ultrafine particles of about 4 to 5 microns with the power of ultrasonic waves, and gently and efficiently spray in the room.

· Sprayed fog disappears quickly, but the ingredients do not fall, they ride in the wind and spread to every corner of the room, and air is sterilized.

· There is nothing to wet the floor.

(It is also called a dry fog, it is a fog which is hardly wet even if you touch it.) · Since it is ultrasonic type, spraying fog is not hot so there is no worry of burning.

- You can use it even in the indoor where elderly people, children, pets are in.

· Approximately 14 tatami matches.

You can use it even at home, small stores and offices.

· Nonstop adjustment amount of atomization amount.

· With sky cooking prevention function.

Features:

• Country of Origin: China
• Contents: 1 unit
• Product size (width X depth X height): width 263 mm × depth 221 mm × height 358 mm

Product information:

Shipping Weight: 2340 g

Package Dimensions: 23.01 x 26.80 x 36.20 cm
