Features
Equipped with a built-in 3G modem - No other bulky devices required
HSPA+ supported with up to 21.6Mbps download and 5.76Mbps upload speeds
2000mAh internal battery for extended hours of outdoor use
Portable and cobblestone design ideal for travel use
Micro USB port for versatile recharging
Equipped with a micro SD card slot for up to 32GB of optional storage
Detail
What This Product Does
TP-LINK’s M5250 is at the forefront of wireless 3G sharing. Equipped with a built-in 3G modem, you can instantly establish your own Wi-Fi hotspot simply by inserting a 3G SIM card at the back of the device. With up to 21.6Mbps download and 5.76Mbps upload speeds, the M5250 is able to provide 3G wireless sharing to up to 10 users simultaneously. Its pocket-sized design and powerful 2000mAh internal battery make it an ideal travel companion, allowing users to work or play for hours on end.
Easy 3G sharing
TP-LINK’s M5250 is at the forefront of wireless 3G sharing, combining the mobility of 3G broadband connections with the flexibility of 802.11n Wi-Fi - No other bulky devices required, simply insert a 3G SIM card to create a 3G Wi-Fi hotspot to share on the move, wherever 3G coverage is available.
Supports HSPA+ High Speed Mobile Wi-Fi
Supporting HSPA+ 3G broadband connections with up to 21.6Mbps download and 5.76Mbps upload speeds*, the M5250 is able to deploy a 3G wireless connection to be shared with up to 10 users simultaneously, providing a fluid and enjoyable Internet surfing experience.
*Actual speed may be limited by ISPs or operation conditions.
2000mAh Internal Battery – Made to Move
With its powerful 2000mAh battery, the M5250 is able to operate for 7-10 hours in typical application*or for 6-7 hours in bandwidth-heavy application* at full capacity. Besides, the device can be flexibly recharged via a micro USB cable to a laptop, portable charger or includes adapter for endless hours of 3G sharing.
*Typical application means one client continuously surfing Internet, receiving/sending e- mails, listening to music online, etc alternatively.
*Bandwidth heavy application means one client continuously downloading large files or watching video online.
*The service time may vary due to signal status.
Micro SD Card Storage
The M5250 is equipped with a micro SD card slot that supports micro SD Cards with capacity up to 32GB, allowing users to insert an micro SD card and plug the device into a PC to use it as an external USB memory stick.
Cobblestone Design
The M5250, informally named “Pebble” is modeled after a sea-eroded stone. Beyond its aesthetic appeal, the slightly rugged nature of the device’s exterior combined with its curved shape make it mold perfectly into the average palm.
Technical Specifications
HARDWARE FEATURES
Network Type
HSPA+/HSPA/UMTS/EDGE/GRPS/GSM
Interface
1 micro USB port for power supply
SIM Card Slot
Micro SD card Slot
Button
Power On/Off Button
Reset Button
Antenna
Internal Antenna
Data Rates
DL: 21.6Mbps, UL:5.76Mbps
Dimensions ( W x D x H )
3.7×2.2×0.8in.(94×56.7×19.8mm)
Power Supply
Internal 2000mAh Rechargeable Battery
Micro SD Card Reader
up to 32G
Band
WCDMA：2100/900MHz
GSM: 850/900/1800/1900MHz
LED Display
Wi-Fi status, Internet connection status, Battery Status
WIRELESS FEATURES
Wireless Standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency
2.4-2.4835GHz
EIRP
<20dBm
