Model: CH2PC2 + NH12
Rechargeable battery format: AA or AAA
Charging capacity: AA NiMH up to 2450mAh AAA NiMH up to 900mAh
Input voltage: 220-230V / 50Hz / 6W
Charging current: DC 1.4V 200mA (AA * 2) DC 1.4V 100mA (AAA * 2)
Instructions
1. Insert the rechargeable battery into the charger as shown in the figure
Insert the rechargeable battery according to the positive and negative (+, -)
2. Connect the power
Plug the charger into a standard AC outlet.
3. Charge
The green LED lights up to indicate that charging is in progress. The charger with a regular power-off function, power off time is set to 18 hours. Remove the battery after the charge is complete, otherwise the charger will continue to charge the battery, charging time is 18 hours, the charger will automatically power off.



Precautions

To avoid personal injury or loss of property due to leakage or fire:
The charger can only charge NiMH rechargeable batteries. Charging other types of batteries may cause the battery to leak, rupture, or explode.
? Do not disassemble or burn the rechargeable battery. Please put the rechargeable battery in the correct direction to avoid using it with other types of batteries. This may cause the battery to short-circuit, leak, heat up, or even explode.
• Use the charger in a cool environment. Do not expose the charger to rain, frost, or excessive humidity.
Do not connect the charger to a towline or receptacle not approved by safety agencies.
If the charger is damaged, do not continue to use.
• Do not disassemble or modify any part of the charger or attempt to use the charger as a power supply unit.
• The power must be disconnected before servicing or cleaning the charger.

This product is not suitable for children or children without parental supervision.




Operating Guide
• During charging, it is normal for the rechargeable battery to heat up; after charging is complete, the battery will gradually return to room temperature.
Please put the rechargeable battery in a cool and dry environment at room temperature.
During the idle period of the rechargeable battery, some of the power will be gradually lost. If the rechargeable battery is not used for a long time, charge the battery before using it again.
If the charger does not work, please refer to the following methods:
* Eraser or dry cloth can be used to clean the positive and negative plates of the battery and charging slot.
* Fully charge the rechargeable battery and recharge it.
? Energize the battery to play the best effect:
* The rechargeable battery must be fully charged before first use.
* The rechargeable battery is placed in a cool dry environment at room temperature.
