Product Description
Quick guide for iOS
1 Press the MODE button and switch to DLNA mode.
2 Connect iOS device to the hotspot of dongle ( SSID: MONTOVIEW-XXXXX, Password: 12345678 ) or your Wi-Fi hotspot ( First use please refer 4.4 and connect dongle to Wi-Fi router ).
3 Control Center > Airplay Mirroring > Choose dongle, TV will share your screen immediately.
4 When the first use please set the dongle connected to Wi-Fi router.
4.1 Connect your iOS device to the hotspot of dongle ( SSID: MONTOVIEW-XXXXX, password: 12345678).
4.2 Open web browser > Visit 192.168.49.1 > Choose Wi-Fi setup > Select your Wi-Fi router > Input password > Connect.
4.3 After connected successfully, You can see the dongle automatically shows SSID and IP address assigned from router.

Quick guide for Android
1 Short press the MODE button and switch to Miracast mode.
2 Open Miracast switch on your Android device and choose MONTOVIEW-XXXXX, the device will automatically connect.
3 After the connection is successful, TV will automatically share your screen.
4 Miracast only provide screen share between your Android device and dongle. Please connect your Android device to Wi-Fi router if need Internet service.
5 There are different names of Miracast on different Android devices, such as WIFI Display、WLAN Display、Wireless Display、Allshare Display、Allshare Cast etc.
6 The way to open Miracast switch on different Android devices is different, you can find it on WLAN、WIFI Setup、Display and so on in the setting menu of your Android device.
