Plasmacluster Loading Humidification Air Cleaner portable IG-EX20
Japan model!! Japan local price!!
※Manual for this product is Japanese.
Conversion plug is the following.
It is a conversion plug for using electrical products of Japan abroad.
To clean the toilet space.
IG-EX20 will reduce the effect of "Odor causing bacteria" to be worried about.
＊Number of technology mark is an estimate of the number of ions per 1cm ³, when measured at a point (1.2m height from the floor) application floor space near the center of the air volume in the "normal" operation.
It is equipped with about twice
※1 the ion concentration "full power" operation. High density plasmacluster ion will reduce the effect of "Odor causing bacteria" attached to the wall or floor.
- ●
- Test agency: Food Institute for Environment and Health
- ●
- Test method：We hang the gauze that was attached the bacteria that cause odor toilet in test space of about 0.65m ³. To release the plasma cluster ion. Then we will collect the gauze in test space. After incubation for 2 days, and calculate the removal rate of bacteria.（Plasmacluster ion concentration：50,000p/cm³※2）
- ■
- Test results: 99% removed in 8 days
- ※1
- Comparison with the 25,000 / cm ³ plasma cluster ion concentration of Air volume "standard" operation.
- ※2
- It is the ion concentration in Air volume "full power" operation, was measured at a point 1.4m in the direction blowing from the body.
If you use the battery case (optional), it can also be used in the place that does not take the power. it play an active part in such as in the closet or in your shoe box, under the sink.
A place you do not want to put your feet and place without the shelf, can be used to over the wall. It is available in a variety of situations.
When you want to send the ions around the body and when you want to change the direction of the ion outlet, IG-EX20 is housed in a body at the bottom of a handy stand.
Of course AC power can also be connected to the USB, and it can be used to connect to a computer in the office difficult to use the outlet. If you use the battery case (optional), it can also be used in the place that does not take the power.
We adopt the ion generating unit for low power consumption. We will deliver a high concentration of plasmacluster ion in large space with less power consumption.
| Model |
IG-EX20 |
| Power |
AC adapter（100～240V 50Hz/60Hz）/ USB |
| The aim of the ion application floor area※1 |
About 1.65m² |
| Operation mode |
Air volume
「Full power」 |
Air volume
「Standard」 |
Air volume
「Weak」 |
| Air volume (m³ / min) |
0.08 |
0.06 |
0.05 |
| Power consumption（W） |
3.0 |
2.4 |
2.1 |
| Electricity bill per hour（円）※2 |
About 0.07 |
About 0.05 |
About 0.05 |
| Sound level（dB） |
31 |
25 |
22 |
| External dimensions（mm） |
Width 90 × Depth 90 × Height 95
（AC adapter、USB cable, louver except） |
| Weight（kg） |
About 0.32
（AC adapter、USB cable except） |
| Accessories |
AC adapter、USB cable、Stand |
| Power cord※3（m） |
About 1.8 |
- ※1
- This is an estimate of the number of ions per 1cm ³, when measured at a point (1.2m height from the floor) application floor space near the center of the air volume in the "normal" operation.
- ※2
- Calculated 22 yen / kWh electricity unit price (tax included).
- ※3
- Please use only the included AC adapter, a USB cable.
Along the steps below, please care.
(The aim of the care: Once every 6 months)
- Attention
- Please stop the operation of the body when you take care. Please disconnect the power cord.
《Failure to do so may result in electric shock or injury》
- Please disconnect the power cord. Remove the bottom cover by opening the screw with a coin.
- You remove the unit holder from body.
- You remove dust on electrode portion by a brush included or a cotton swab.
Attention in case of the care
●Please do not touch with your finger to the electrode portion.( There is a risk of injury. )
●Please don't deform the electrode. Please don't touch the terminal.（It may cause failure）
For stubborn dirt・・・・・・Please care for it after moistened with a little water a cotton swab.
- You attach the unit holder.
- You attach the bottom cover.①You plug nail of bottom cover into the body, install the bottom cover.
②You tighten the screw with a coin.
- Please plug firmly connection terminal to the body.
Cleaning the filter （The aim of the care ： About once a month)
- Please sucking dust from the suction port of the side of the body with cleaner.
Please not too firmly.
- Please disconnect the power cord. Remove the bottom cover by opening the screw with a coin.
- Please remove the filter from the body. Please sucking dust of filter with cleaner.
Please replace the filter.
For stubborn dirt・・・・・・
Please wash the filter with water.
（Please use a soft sponge when it is hard to get.）
Attention in case of the care
●Please do not drain the electricity left open the bottom cover.
●When you wash, please attach it after drying thoroughly in the shade always.
●If you care to put it in a place tend to scar, please put it on the cloth.
- You attach the bottom cover.
- You plug nail of bottom cover into the body, install the bottom cover.
- You tighten the screw with a coin.
- Please plug firmly connection terminal to the body.
