• The MWE delivers everything you expect from top tier power supply at a budget price. This unit also comes with a circuit design that will protect your system at all times. The 120mm fan keeps your system cool with little noise. This tough little box is the perfect solution for all your power needs.

    High Efficiency and Low Noise

    with Active Power Factor Correction design and forward topology. Meeting the 80 PLUS certification for 230V, the MWE will guarantee a typical efficiency of at least 85% during normal use.

    ErP 2013 Lot 6 Compliant

    The MWE is designed to the latest envirmental regulations and standards, meeting the ErP 2013 mandates. The MWE consumes less then 0.5 Watt when your system is in standby mode, which not only reduces strain on the environment but also your energy bill

    Proven Thermal Resistance

    The MWE is engineered to operate normally at up to 40°C, providing added security and reliability to systems operating in warmer environments.

    Quiet and Durable

    The thermally controlled 120mm HDB fan operates smoothly without friction. Enjoy your system with a durable fan in a quiet environment.

    Damage Resistant

    The MWE provides you full standard protection (OVP/SCP/OPP) plus built-in Over Temperature Protection (OTP). These extra security measures minimize the risk of damage to your system from power outages.





    Specifications



    Product Name MWE 450
    Product Number MPW-4502-ACABW
    Type Intel Form Factor ATX 12V V2.31
    PFC Active PFC (>0.9 typical)
    Input Voltage 200-240 Vac
    Input Current 3.5A
    Input Frequency 47-63 Hz
    Dimensions (LxBxH) 150 x 150 x 86mm
    Fan Size 120mm
    Fan Bearing HDB
    Fan Speed 725-1460 RPM
    Power Good Signal 100-500 ms
    Hold Up Time >14 ms
    Efficiency 85% Typically Load
    ErP 2013 Lot 6 Yes
    MTBF >100,000 Hours
    Operating Temperature 40°C
    Protections OVP / OPP / OTP / SCP
    Regulatory CE, TUV, EAC, RCM, CCC
    Connectors MB 20+4 Pin 1
    CPU 12V 4+4 Pin 1
    SATA 6
    4 Pin Peripheral 3
    FDD Cable 4 Pin 1
    PCI-e 6+2 Pin 2
    Warranty 3 Years
