Product Description
Product Description Features:
1.Frequency range:467.5125MHz-467.675MHz(14 channels)
2.US FRS:462.5625-467.7125MHz(14channels)
3.EU PMR+FRS:446.00625-467.7125(22 channels)
4.14 channels
5.1W output power
6.38 groups of CTCSS
7.5 call tone selectable
8.VOX function
9.Monitor function
10.Key lock Function
Technical Specifications:
General
Rated Voltage DC 3.6V-4.5V
Modulation Mode FM Modulation
Intermediated Frequency The first intermediate frequency:21.7MHz
The second intermediate frequency:450MHz
Total Power Consumption 1W
Transmitter Power Output Max 100mW 4.5DC
Frequency Error 0.00025%
Current Consumption Tranmitting < 450mA / Receiving < 150mA / Standby < 45mA
Receiver Sensitivity for 12dB -118dBm
Audio Output 0.25W 8OHM (5% distortion)
Audio Response Range 300-3200Hz
Feature
1.High Quality: Long standby with rechargeable batteries; passed 1.2 meter drop test; Durable and environmental materical, safe and suit for kids.
