Item Descriptions:

Caution:

1.

Shutdown (the file was saved automatically) after a fast red / bull flash of 5 seconds when the power supply is insufficient.

2.

If a memory card is not inserted, shut down after 5 seconds of red · bull flash.

3.

Shut down after 1 minute if you do not operate anything with it on.

"TEBAK CAM" store

Products purchased from,

We offer free exchange service

Product specification:

Movie format: AVI

Motion: M-JPEG

Movie resolution: 1920 * 1080P

Frame rate: 30 fps

Photo format: JPG

Photo resolution: 12 M (4032 * 3024)

Video Proportion: 16: 9

Supported OS: Windows me / 2000 / xp 2003 / vista; Mac OS; Linux

Operating time: about 150 minutes

Charging voltage: DC-5V

Storage support: Up to 32GB TF card

Transmission speed: High speed USB 2.0

Interface: Mini 8 pin USB

Battery type: lithium polymer

Recording:

Blue light turns on after start up, and enters standby mode.

When you press the ON / OFF button once, the blue light flashes (gently flashing), and 1080P recording starts.

Press again to save the recording and return to standby mode at the same time.

(You can record up to 5 minutes at a time, you can record again in the same way.

Infrared light mode:

In the recording state, press the mode button

once

When pressed, the blue light blinks (quickly flashes) and the infrared light mode is set.

When the mode button is pushed once again, the blue light flashes (gently blinks), the infrared light mode is closed and the mode is returned to the recording mode

Shooting:

When you press the MODE button briefly from standby mode, the red light and the blue light will light at the same time and the recording standby mode will start.

ON / OFF button Once pressed briefly, the red light flashes once, the picture is taken and saved.

Press the MODE button once again to return to the standby mode

Motion detection Recording:

When you press the MODE button for about 3 seconds from standby mode, the red light flashes (gently blinks), and the standby mode for motion detection recording starts.

During recording, when you find a moving object, the red light flashes (blinks quickly), and motion detection recording starts.

If there is no moving object, the recording stops, the red light flashes (gently blinks), it is kept in standby mode all the time and shut down for power reduction.

(* It can record up to 5 minutes, it is saved, it starts recording automatically automatically, it is a recording to repeat.)

Press the ON / OFF button once again to return to the standby mode

Infrared light mode:

In the motion detection recording state, pressing the M button once, the red light and the blue light alternately flash and the infrared light is opened.

When I press the M button once again, the red light blinks (gently flashing) and the infrared light stops.

Return to standby mode of motion detection detection recording

reset:

When the product is unresponsive, pressing the ON / OFF key and the mode key at the same time resets the machine

Time set:

Connect the USB cable to the PC, pop up the removable hard disk with "My Computer", set "TIMERSET" and open it.

1: 20160307142432 Y (time watermark is displayed)

2: 20160307142432 Set time format according to the method of N (time watermark not displayed), divide by year, month, day with hour, minute, second by space.

Then save it.

Saving it safely after saving the file.

Restart, time setting is completed

Recording while charging:

TF

Insert the card and turn it off,

Connect to the USB 5 V charger or mobile power supply, and recording starts.

Stop recording with any button

charging:

When charging, the red light flashes gently.

When charging is complete, the red light turns on.

Application location

We instantly deliver video in the fields of conference, business negotiation record, various business scenes, nursing care, monitoring of shops, lectures, accidents, crime records, crime prevention.

Also to protect important people such as nursing homes and babysitter suspected abuse.

This product is intended for crime prevention and security to protect important families and property.

Features:

• Please enter model number Confirm this is compatible:
• High quality image Hi - vision, FULL HD 1080P DV DC 1920 * 1080P
• Built-in high capacity lithium lithium battery, sustainable imaging 150 minutes, up to 32 gb memory cards to support
• 8 Feng Shui Outdoor Light, super strong night vision effect.
• 8 light infrared light (invisible), the night visibility is strong.
• In the case of low illuminance, it is also possible to record high-definition shooting
• Exquisite design, portable video camera
• Combine versatile stents to accommodate different environments

Product information:

Shipping Weight: 208 g

Package Dimensions: 5.21 x 12.39 x 19.51 cm
