Brief introduction | |
XMT -9000 intelligent temperature controllers are the multi-functional regulators adopting the micro processing units. As also adopting the switch power source and Surface Mount Technology(SMT)， it is small and has great performance. The special self-diagnosis， self-conditioning and intelligent functions bring good efforts through simple operating. | |
Characteristic | |
1.Display pv value and SV value by the high brigh red and grenn double-row digital tube | |
2.Appointed input by sensing signal | |
3.Automatic amend by sensing unit | |
4.Function of second class data lock protection | |
5.Alarm rang:free set the complete range | |
6.Operating power supply:Switch power:85-264VAC 50/60Hz | |
Main technologies indicates | |
1. Input | |
Any kind of TC， RTD's standard signal of current and voltage (see the kinds sheet of input) | |
2. Accuracy | |
Measure accuracy | ±0.5%FS |
Cold-end Compensation deviation | in the range of ±2°C(0~502°C can be amended by the software) |
Resolving power | 14bit |
Sampling cycle | 0.5 Sec |
3. Display | |
PV，SV | -1999 ~ +1999 |
Indicatesof output，alarm，self-conditioning | LED |
4. Controlling output | |
Current output | DC 0~10 mA， 4~20 mA (RL< 500Ω) |
Voltage output | DC 0~5 V， 1~5 V (RL>10K) |
Relay output | contact capacity 250VA (resistance load) |
Voltage pulse output | 0~12V， (suitable for the solid relay SSR) |
Controlled Silicone SCR output | over zero trigger or phase trigger(resistant load) |
Alarm function output | 2 groups output at most， 12 modes. |
Capacity of the output contact | 250V AC 3A (resistant load) |
5. Setting range | |
Setting value (SV) | Measured Present Value (PV) |
Proportional band (P) | 0 ~ whole measured range (when set 0， it's ON/OFF control |
Integral time | 0~3600 Sec (when the time is 0， the function of integral time closed) |
Derivative time | 0~3600 Sec (when the time is 0， the function of differential time closed) |
Proportional term | 1~100 Sec |
Hysteresis loop Width of the phase controlling output | 1~100°C (or other pv units) |
6. Others | |
Insulation resistance | >500 M (500DC) |
Insulation strength | 1500VAC/1min |
Power consumption | <10VA |
Using environment | 0~50°C， 30~85% RH no corrosive atmospheres environment |
Weight | about 0.5kg |
