Product Description

Specification:
1. 2.4G wireless DMX512 R/T
2. 126 channels jumping frequency automatically, high anti-jamming ability, to ensure works reliability
3. 7 groups ID code settable, User can use 7 groups individual wireless net without any interfere.
4. Each other in the same place (Tricolor LED displaying Indicators)
5. Input voltage: 5VDC 500mA MIN
6. Communication distance: 400M (visible distance)
7. Work frequency section: 2.4G ISM, 126 channels, frequency section
8. Max transmitting power rate: 20dBm
9. Receiver Sensitivity: -94dBm
10. CPU: 32-bit ARM Core
11. Modulation: GFSK
12. DMX Signal Interface: RS485
13. Operating temperature: -40 ~ 85 °C
14. Storage Temperature: -65 ~ 150 °C
15. Ambient Relative Humidity: 5 to 95% (non-condensing)
16. Automatic Reboot Trigger: Built-in WDT (watchdog timer)
17. Warranty Period: 3 years
Note : When using it , please pull up and down the antenna ,don't move the antenna heavily .

Package included:
1 x DMX512 wireless transmitter(US Plug)
1 x DMX512 wireless transmitter(US Plug)
2 x Power adapter

Feature

DMX512 wireless receiver/transmitter transmits standard DMX512 protocol data (generated by console) by wireless way. No time delay when signal data is transmitting, signal data is real time and reliably.
This product adopts a 2.4G ISM frequency section. High effective GFSK modulate, communication design; 126 channels jumping frequency automatically, high anti-jamming ability.
1. 2.4G wireless DMX512 R/T
2. 126 channels jumping frequency automatically, high anti-jamming ability, to ensure works reliability
3. 7 groups ID code settable, User can use 7 groups individual wireless net without any interfere.
Brand : Donner
Item model num : TS-WDMX01B
MPN(PartNumber) : TS-WDMX01B
EAN : 0612306366249
Product Dimensions(LxWxH) : 16x3x12cm ; 295 g
Package Dimensions(LxWxH) : 23x16x6cm ; 295 g
