TP-Link AC1900 Wireless Gigabit Router (Archer C9)
TP-Link AC1900 Wireless Long Range
Wi-Fi Gigabit Router (Archer C9)
- ㆍProduct Highlights
- Wireless AC1900 WiFi. Supports 802.11ac, the next generation of Wi-Fi
- Stream 4K Ultra HD video and game online without lag over a clear 5GHz band while using the 2.4GHz band for everyday tasks
- Simultaneous dual band networks, 2.4GHz (600Mbps) and 5GHz (1300Mbps)
- 3 detachable high performance antennas for maximum wireless coverage and reliability
- Beamforming technology locates wireless devices to create a stronger connection
- Powerful 1GHz dual-core processor handles simultaneous wired and wireless connections without interruption
- USB 3.0 and 2.0 ports to easily share printers, files, and media across your network
- TP-LINK Live 24/7 technical support for assistance with setup and configuration
-The Archer C9 creates a reliable, blazing-fast network using 802.11ac, the latest, most powerful Wi-Fi technology. Stream 4K Ultra HD video and game online without lag over a clear 5GHz band while using the 2.4GHz band for everyday tasks like checking email and web browsing. The C9's dual USB ports make it easy to share files, photos, and music across your network, and beamforming technology helps the router strengthen its connections to Wi-Fi devices. - ㆍSpecification
- Dual Band 2.4GHz (up to 600Mbps) + 5GHz (up to 1300Mbps)
- 1GHz Dual Core Processor
- 3x Dual Band External Antennas
- 4x 10/100/1000Mbps Ethernet Ports + 1x Gigabit WAN Port
- 1x USB 3.0 + 1x USB 2.0 Ports
- Beamforming - ㆍWhat is in the box ?
- Body
- Power adaptor
- LAN cable
- Manual
HARDWARE FEATURES Interface 4 10/100/1000Mbps LAN Ports,
1 10/100/1000Mbps WAN Port
1 USB 3.0 Port + 1 USB 2.0 PortButton WPS/Reset Button,
Wireless On/Off Button,
Power On/off ButtonAntenna 3 dual band detachable antennas External Power Supply 12V/3.3A Dimensions ( W x D x H ) 8.7 X 3.4 X 6.6 in. (221 X 86 X 168.5mm)
WIRELESS FEATURES Wireless Standards IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHzFrequency 2.4GHz and 5GHz Signal Rate 5GHz: Up to 1300Mbps
2.4GHz: Up to 600MbpsReception Sensitivity 5GHz:
11a 6Mbps: -94dBm
11a 54Mbps: -76dBm
11ac HT20: -68dBm
11ac HT40: -64dBm
11ac HT80: -60dBm
2.4GHz
11g 54M: -77dBm
11n HT20: -73dBm
11n HT40: -71dBmTransmit Power CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
FCC:
<30dBmWireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryption
SOFTWARE FEATURES Quality of Service WMM, Bandwidth Control WAN Type Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access)/BigPondManagement Access Control
Local Management
Remote ManagementDHCP Server, Client, DHCP Client List,
Address ReservationPort Forwarding Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS DynDns, Comexe, NO-IP VPN Pass-Through PPTP, L2TP, IPSec Access Control Parental Control, Local Management Control, Host List, Access
Schedule, Rule ManagementFirewall Security DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address BindingProtocols Supports IPv4 and IPv6 USB Sharing Support Samba(Storage)/FTP Server/Media Server/Printer Server Guest Network 2.4GHz guest network × 1
5GHz guest network × 1
OTHERS Certification CE, FCC, RoHS Package Contents AC 1900 Wireless Dual Band Gigabit Router Archer C9
3 detachable antennas
Power supply unit
Ethernet Cable
Quick Installation GuideSystem Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8/8.1/10
MAC OS, NetWare, UNIX or LinuxEnvironment Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
