Studio : Cane Creek Publisher : Cane Creek Binding : Misc. Product Description
Cane Creek 40 series Bottom Assemblies - Replaces Cane Creek XX-44 headset
- Bottom assemblies include bottom cup, sealed oxide bearing, and crown race
- EC44/40 Conversion Bottom fits 1-1/8" 44mm standard head tube bottom (44mm inner diameter)
- Consistent stack heights across 10, 40 and 110 Series
- For use with 1.5" threadless steerer tube bottom (40mm crown race seat diameter, tapered steerer tube)
- Internal parts are cross-compatible across 10, 40 and 110 series
- Converts 44mm head-tube bottom for use with 1.5" 40mm crown race forks
- Durable steel crown race with low-friction face-seals
- External Cup (EC) 44mm Bottom Assembly enables use of tapered steerer tube
- External Cup (EC) assemblies feature press-in cups with bearings outside the frame
- Combine with 44mm 1-1/8" ZeroStack Top Assembly for complete 44mm straight head-tube installation
- Internally relieved AL-6061 T-6 cup
- Assembly includes 1.5" black oxide steel bearing and 40-Series 1.5" crown race
| Item Specifications |
|---|
| Color | Black | | Weight | 50g | | Material | Aluminum | | Steerer Tube | 1.5" | | Crown Race | 39.7 | | Stack Height | 1mm | | Bearing Type | Black Oxide Sealed | | Headset Type | Integrated, 52.0mm OD, 45 degree bearing (1.5") | | S.H.I.S Lower | IS52 |
