- Binding : Electronics

- Brand : SunFounder

- EAN : 0701715366466

- Feature : Link to download the instructions https://www.adrive.com/public/9zUKSu/Raspberry%20Pi%202.8TFT.pdf / It features a 2.8" display with 320x240 16-bit color pixels and a resistive touch overlay. The plate uses the high speed SPI interface on the Pi and can use the mini display as a console, X window port, displaying images or video etc. Best of all it plugs right in on top! / It is designed to fit nicely onto the Pi Model A or B. But it is NOT compatible with Model B+. / Uses the hardware SPI pins (SCK, MOSI, MISO, CE0, CE1) as well as GPIO #25 and #24. All other GPIO are unused. Since we had a tiny bit of space, there's 4 spots for optional slim tactile switches wired to four GPIOs, that you can use if you want to make a basic user interface. For example, you can use one as a power on/off button. / Note: The Raspberry Pi is NOT included

- Label : SunFounder

- Manufacturer : SunFounder

- Model : TFT28 Touch Shield

- MPN : 2.8"TFT

- PackageQuantity : 1

- PartNumber : 2.8"TFT

- ProductGroup : PC Accessory

- ProductTypeName : MONITOR

- Publisher : SunFounder

- Studio : SunFounder

- Title : SunFounder 320x240 2.8" Assembled TFT Touchscreen Display LCD for Raspberry Pi

- UPC : 701715366466
