Product details of Supercart DC-DC 3-35V 12V to 3.5-35V 100W Boost Step-up ModulePower Supply LED Voltmeter

Dear Buyer、Thanks for You Purchase 、IfYou Are Satisfied with Our Product 、Could You Please Leave Us 5Star Feedback ? That's Very Important for Us 、Thank You Very Much.

Product Details:

Boost Step-up Module

Condition: New

Input Voltage:3-35V DC (Note: Wheninput voltage is less than 4V、 onboard voltmeter will not work)

Input Current:9A (max)

Output Voltage:3.5-35V DC (this boardis boosting board、 output voltage>=Input voltage)

Output Current:6A (max)

Output Power: 75W (when the input andoutput voltage greater than 20V up to 128W)

Conversion Efficiency: 96.7% (thehighest)

Output Ripple: 24mV(TYP)

Onboard Voltmeter Range:4-40V、error:+/-0.1V

Circuit protection: yes、 (limitcurrent 14A)

Size: 67 x 43 x 12mm

Color as pictures

PLS NOTE that due to lighting effects、monitor"s brightness/ contrass settings ect、 there could be someslight differences in the color tone of the pictures and the actualitem!

Specifications of Supercart DC-DC 3-35V 12V to 3.5-35V 100W Boost Step-up ModulePower Supply LED Voltmeter

• 1 x Boost Step-up Module
