One Year Warranty

2017 New Original Two lens Car DVR Dual Camera G30 1080P Video Recorder With Rear View Cameras Night Vision Loop Recording Camcorder BlackBox

Item specifics

Item Type: Car DVR
Interface: AV-Out,SD/MMC,HDMI,Micro SD/TF,USB2.0
OSD Language: Spanish,French,Japanese,Portuguese,Thai,Chinese (Simplified),Russian,Chinese (Traditional),Italian,German,Russia,English,Korean
Battery: Built-in
Special Features: SD/MMC Card,Real Time Surveillance,Time&Date Display,Cyclic Recording,Microphone,Led Display,Motion Detection,Anti Vibration,Cycle Recording,G-sensor,Night Vision,Led Light
Number Of Lenses: 2
Original Package: Yes
Screen Ratio: 16:9
Max External Memory: 32G
Frames Per Second: 30
Touch Screen: No
Display Size: 2.7"
Video Format: AVI
Video Code: MJPG
GPS logger: None
Assembly Mode: Portable Recorder
Memory Card Required Reding Speed: Class 10
Pixels: 500Mega
Camera Resolution: 1920x1080
View angle: 140°
Imaging Sensor: 1/4 Color Cmos

Notice: Due to these car cameras are of high quality, the Micro SD Card writes fast when recording. So it needs high speed Original Class 10 Micro SD Card. If you do not have one, you can buy one with your order. If you have any question, please contact us at the first time so that we can help you. Some issue finally turned out to be it caused by not using an Original Class 10 Micro SD Card or wrong setting/operation.

Car DVR

1920 x 1080 p FULL HD resolution
140 degree A + grade high - resolution wide Angle lens
The Advanced photography compression will technology
2.4 inch high resolution LCD, can watch while shooting
Night vision function
Support HDMI full HD video transmission
Support TF memory card up to 32 gb
Seamless loop - cycle recording function
Motion detection function
G - sensor function
Language support: English, Russian, French, German, Italian, Spainish, Japanese, Korean, Thai, Portuguese, Chinese

Backup Camera

View angel: 170°
Image chip: 1/3 Inch Color CMOS
TV System: NTSC /PAL
Effective pixels: 628*582 pixels
Horizontal Resolution(TV lines): 420 TV lines
Power Supply: DC 12V
Operating Temperature:-40°C~+80°C, RH95% Max
Video Output: RCA connector, 1.0VP-P, 75Ohm
S/N ratio: more than 48db
Electronic shutter: 1/50-1/10000 seconds
IP Rating: IP68

Package Contains:

1 x G30 Car DVR with Backup Camera
1 x Car charger
1 x USB cable
1 x Bracket
1 x User Manual
1 x Retail Box

Kindly remind:

1.It needs a micro SD card, which should be original and high speed C10, 4-32GB.Be carful there are many copies in the market.
2. Do not charge via usb cable from computer, please charge via the 12V car charger. It may burn the motherboard if on truck of 24v power, please add a 24v to 12v converter.
3. To keep driving safe, as the car temperature is very high when outdoors in summer, if large battery, it will be easy to explode,so the battery of car DVR are produced very small. The battery is only to save the video when power off suddenly. Therefore please charge via car charger when used.
4. How to loop recording?
1> Please turn on the loop recording in the menu.
2> Please format the card in the camera before use.
3> Please turn low or off the G-sensor due to the high sensitivity, it will save many videos which can't be cycle covered, so the card is filled full soon, then it stops the video.
5. View Angle:

The angle showed in the display is not the view angle, please play the video on computer, it will be larger and clearer than in registrar.

Car Camera , Car DVR , DVRs , Dash Cam , DashCam ,Registrator, Registrar, Black Box, Car Recorder, Video, Auto, Vehicle,Camcorder,carcam

C0044BK-6

R0003-1

C0044BK-3

-------------------------------------------------------------------------------------------------------------------------------------------

12V/24V to 5V Adapter

12V/24V convert to 5V Power Voltage adapter with cable for Car Camera DVR

With this power adapter, you can draw power from car battery for long stand by recording, until the car power is used up. If you need 24hours recording, you need it.

Note: The car camera will Loop Record automatically according to your setting

ttt

12V 24V TO 5V Adapter Install Tutorial
http://v.youku.com/v_show/id_XNzg1MzI0NTc2.html?from=y1.2-1-176.4.8-1.1-1-2-7-0

Please use an Original High Speed Class 10 SD Card, If you don't have, order one from us. Because the item writes fast when recording, so it needs Original High Speed Class 10 SD Card. Thanks
