Legris 3118 56 20 Nylon & Nickel-Plated Brass Push-to-Connect Fitting, 90 Degree Banjo Elbow, 1/4" Tube OD x #10-32 UNF Male
[Product Information]
- 90-degree banjo elbow to connect a tube to a female threaded connection at a 90-degree angle
- Push-to-connect tube connection on one end and male UNF threads on the other end
- Nylon body and nickel-plated brass sub-base
- Handles pressures up to 290 psi (20 bar), operating temperature range of-20 to +80 degrees C (-4 to +176 degrees F), and a vacuum capability of 755 mm Hg
- Meets RoHS and ISO 14743 technical specifications
