Product Description

What This Product Does

TP-LINK’s TL-SG108 provides an easy way to expand your wired network. All 8 ports support Auto-MDI/MDIX, eliminating the need to worry about what type of cable to use. Featuring full duplex mode, the device can process data at a rate of up to 2000Mbps, making it an ideal choice for expanding your high performance wired network. Moreover, with innovative energy-efficient technology, the TL-SG108 can save energy up to 72%.

Key Features

Gigabit Switch

Featured with 8 10/100/1000Mbps ports, the TL-SG108 enables ultra-fast wired connectivity, enabling instant large files transferring.

Steel Housing

The TL-SG108 is housed in a compact steel case for longer life span. With the desktop or wall-mounting design, you can place the device wherever it’s convenient.

Easy to Use

The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network

Go Green with Your Ethernet

The TL-SG108 features the latest innovative energy-efficient technologies that can save power up to 72%. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

Specifications

Support IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
Support QoS (IEEE 802.1p)
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
16Gbps Switching Capacity, 8K MAC address table, 12KB Jumbo Frame, 2MB Buffer Memory
Auto-MDI/MDIX eliminates the need for crossover cables
Support MAC address auto-learning and auto-aging
Auto-negotiation ports allow smart integration between 10Mbps, 100Mbps, and 1000Mbps devices
Fanless desgin to keep a quiet environment
Support 100-240V power supply

What's in the Box

8-Port Gigabit Switch
Power Adapter
User Guide

TP-LINK Unmanaged Switches Series

Which Unmanaged Switch is Right for Me?	TL-SG1005D	TL-SG1008D	TL-SG105	TL-SG108	TL-SG1016D	TL-SG1024D	TL-SG1016	TL-SG1024

Product Name	5-Port Gigabit Desktop Switch	8-Port Gigabit Desktop Switch	5-Port Gigabit Desktop Switch	8-Port Gigabit Desktop Switch	16-Port Gigabit Desktop/Rackmount Switch	24-Port Gigabit Desktop/Rackmount Switch	16-Port Gigabit Rackmount Switch	24-Port Gigabit Rackmount Switch
Case Material	Plastic	Plastic	Steel	Steel	Steel	Steel	Steel	Steel
Port Number	5	8	5	8	16	24	16	24
Size	Desktop	Desktop	Desktop	Desktop	13-inch	13-inch	19-inch	19-inch
QoS	-	-	✓	✓	-	-	-	-
IGMP Snooping	-	-	✓	-	-	-	-	-
AUTO MDI/MDIX	✓	✓	✓	✓	✓	✓	✓	✓
IEEE 802.3X Flow Control	✓	✓	✓	✓	✓	✓	✓	✓
Power Saving	✓	✓	✓	✓	✓	✓	✓	✓
Plug and Play	✓	✓	✓	✓	✓	✓	✓	✓

Feature

12K Jumbo frame improves performance of large data transfers
8 gigabit port switch Ethernet connection integrates 10/100/1000Mps with Auto-Negotiation
Plug and play no configuration required
Innovative energy-efficient technology saves power up to 72%
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
IEEE 802.3x flow control provides reliable data transfer
Fanless design ensures quiet operation
Industry-leading 5-year warranty and unlimited technical support. Technical Support: +1 866 225 8139; Hotline en Français: +1 855 987 5465.
TP-LINK Live 24/7 Technical Support
Featuring full duplex mode, the device can process data at a rate of up to 2000Mbps
Brand : TP-Link
Item model num : TL-SG108
MPN(PartNumber) : 2610606
EAN : 0803982830517
Product Dimensions(LxWxH) : 16x11x3cm ; 640 g
Package Dimensions(LxWxH) : 19x13x11cm ; 640 g
