Item Descriptions:

Color:

Silver

Product introduction

· USB streaming playback of digital music exceeding CD sound quality from Windows and Mac · Jitter further reduced by up-conversion to 92 kHz · Left and right independent D / A converter, dual monaural configuration · All components · circuit performance is drawn out

Strong power supply (adopt toroidal core · transformer) · Shunt regulator circuit that provides stable current to D / A converter requiring high-speed processing · Analog circuit design devoted to simple signal path · As high-end headphone amplifier

Also possible to combine with optimum · outstanding Hi-Fi system · Input terminal · Detailed design that sticks to ease of use and quality · Easier operation even from iPhone and iPod touch with Remote application installed ※ Remote application

It is not included.

From Amazon

USB-DAC leading to new ground of PC audio

Dual monaural USB-DAC that can enjoy PC audio in high quality.

We will introduce advanced digital processing technology and review the analog circuitry to achieve astonishing dynamic range and low distortion ratio and propose a new approach to PC audio that high sampling digital audio opens up.

USB streaming playback of digital music from Windows and Mac

Stream playback by digitally transferring digital audio sources saved on Windows or Mac to a maximum of 24 bits / 192 kHz.

Data transfer corresponds to the asynchronous mode in which timing control is performed by a high precision internal clock, and digital audio processing is performed in a pure state excluding jitter caused by the clock accuracy of the personal computer side.

Dual monaural configuration of left-right independent D / A converter

For the heart D / A converter, PCM 1795 made by BurrBrown is placed on each channel.

By configuring the dual monaural configuration, the left and right channels will not interfere with each other, and the performance of a high-performance D / A converter can be maximized.

Furthermore, a shunt / regulator circuit is adopted as a circuit that supplies current to this D / A converter, and even when the D / A converter requires high-speed processing, it is possible to prevent occurrence of ground noise due to load variation of supply voltage

Analog circuit design devoted to a simple signal path

Pattern layout is bilaterally symmetrical so that the signal paths of the left and right channels are the same distance.

Furthermore, a large relay switch is adopted as a muting circuit, and it designed to be a simple signal path excluding the transistor which becomes a source of distortion.

MUSES 8920 is adopted as an operational amplifier, and high sound quality of analog output including headphone output was realized.

A powerful power supply unit that draws out the performance of all parts and circuits

Adopting a large-capacity toroidal core power transformer that can supply high efficiency and stable current.

Suppresses magnetic flux leakage and prevents electromagnetic induction of noise.

The primary power switch employs a primary switch to keep standby power consumption to zero.

Ideal as a high-quality headphone amplifier

For the headphone amplifier, an operational amplifier of the same quality as the line output is adopted.

You can enjoy the world of 192 kHz high sampling digital audio by the right and left independent D / A converter even in the environment where attention to the surroundings such as late night and apartment houses is necessary.

Features:

• Please enter model number Confirm this is compatible:
• ● USB streaming playback of digital music over CD sound quality from Windows and Mac
• ● Up conversion to 192 kHz further reduces jitter
• ● Dual Monaural Configuration of Left and Right Independent D / A Converter
• ● Analog circuit design aimed at a simple signal path
• - Ideal as a high-quality headphone amplifier

Product information:

Shipping Weight: 2422 g

Package Dimensions: 12.19 x 31.19 x 35.00 cm
