The extender offers the most convenient solution for HDMI extension over a single Cat5e/6 with long distance capability, and is the perfect solution for any application.?

Operating and Connecting:

1. Connect one HDMI cable between source device and TX Extender, the max cable distance is 10 meters.

2. Connect one HDMI cable between display device and RX Extender ,the max cable distance is 10 meters .

3.Connect single cat-5e or cat6(recommended) cables between TX and RX Extender, the max cable distance is 50 meters.

4. The 2 pair of IR TX and IR cable connect the 3.5mm IR RX AND IR TX Port pf the receiver and transmitter respectively.

5.Connect 5V power supply to the TX and RX.

6.LED indicator light:

TX LED indicator light: When there is no signal input ,it turns blue; When there is signal input ,it turns red

RX LED indicator light: When there is no signal input ,it turns blue; When there is signal input ,it turns red

Package Contents:

Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton:

1)one piece of HDMI fiber extender transmitter

2)one piece of HDMI fiber extender receiver

3)two pieces of HC 5V power supply

4)one pair of IR transmitter and receiver

5)User's manual
