-. Binding : Electronics
-. Brand : Potter
-. Feature : NEMA Type 4X / Description TheRMS-6T-EXP-WPis a high-quality, die-castmetal, explosion-proof manual fire alarm pull station available in either single or dual action configurations. The RMS-6T-EXP-WP is approved for NEMA-4X applications and is UL Listed and Factory Mutual Approved for use in Class I, Groups B, C, and D; Class II, Groups E, F, and G; and Class III hazardous environments. The RMS-6T-EXP-WP has a DPDT switch with terminal strip connections. Operation TheRMS-6T-EXP-WPsingle-actionstationisoperatedsimplybypulling the pull handle on the front of the station as far down as it will go, at which point the handle locks into place, and is easily visible from up to 50 feet. The activated station is reset by opening the station with a key, placing the handle in the normal, upright position, and re-locking the station. Optional dual action Lift and Pull or Break Glass adapter offer added security against unwanted activation without complicating the overall pull station operation. Architects And Engineers Specifications The manual pull station shall be UL Listed and FM Approved for Explosion-Proof, Marine and NEMA 4X applications for use in the intended environment. It shall be painted red with raised white identification lettering. The station shall have two sets of form C contacts. It shall be a non-coded, single-action station that shall latch in the activated position. When activated, the latched handle shall be easily recognizable as being in the activated position when viewed from a distance of at least fifty feet.Alocking mechanism shall be provided to prohibit unauthorized reset ofthe manualstation.Akey shall be required to unlock and reset the station. RMS-6T-EXP-WP EXPLOSION-PROOF MANUAL PULL STATIONS PRINTED IN USA MKT. #8880014 - REV F 1/10 Ordering Information Stock No. Model No. Description 1000400 RMS-6T-EXP-WP Single-action explosion-proof manual pull station Accessories LP: Lift and Pull (Dual action)
-. Label : potter
-. Manufacturer : potter
-. MPN : RMS-6T-EXP-WP-LP
-. PackageQuantity : 1
-. PartNumber : RMS-6T-EXP-WP-LP
-. ProductGroup : Photography
-. ProductTypeName : SURVEILANCE_SYSTEMS
-. Publisher : potter
-. Studio : potter
-. Title : Potter RMS-6T-EXP-WP-LP Lift and Pull (Dual action) Emergency fire alarm explosion / weather proof pull station
