TP-LINK Archer C50 AC1200 Wireless Dual-Band

• ㆍProduct Highlights

  - Brand : TP-LINK

  - Model : Archer C50 AC1200

  - Supports 802.11ac - The next generation of Wi-Fi

  - Dual band – for combined wireless speeds of up to 1.2Gbps at 2.4GHz and 5GHz band concurrently

  - 2 dual band external antennas provide stable wireless connections and optimal coverage

  - USB Port – easily share a printer locally and files & media with networked devices or remotely via FTP server

  - Easy network management at your fingertips with TP-LINK Tether

  - Guest Network Access provides secure Wi-Fi access for guests sharing your home or office network

  - IPv6 supported, meeting the demands for the next generation of Internet

  - IP-based Bandwidth Control makes it easier for you to manage the bandwidth of devices connected to the router

  - Wi-Fi On/Off button allows users to turn their wireless radio On or Off

  - Easy one-touch wireless security encryption with the WPS button

  - WPA-PSK/WPA2-PSK encryptions provide user networks with active defense against security threats

  - Easy Setup Assistant with multi-language support provides a quick & hassle free installation process




• ㆍSpecification



  Hardware Features
  Interface	4 x 10/100 Mbps LAN Ports  1 x 10/100 Mbps WAN Port  1 x USB 2.0 Port
  Buttons	WPS/Reset Button  Wireless On/Off Switch  Power On/Off Button
  External Power Supply	12 VDC, 1.5 A
  Antenna Type	2 x Dual Band antennas




  Wireless Features
  Wireless Standards	IEEE 802.11ac/n/a 5 GHz  IEEE 802.11n/g/b 2.4 GHz
  Frequency	5 GHz and 2.4 GHz
  Signal Rate	5 GHz: up to 867 Mbps  2.4 GHz: up to 300 Mbps
  Reception Sensitivity	5 GHz 11a 54M: -76dBm 11ac VHT20 MCS8: -70 dBm  11ac VHT40 MCS9: -65.5 dBm  11ac VHT80 MCS9: -61.5dBm  2.4 GHz 11g 54M: -76 dBm  11n HT20 MCS7: -74 dBm  11n HT40 MCS7: -71 dBm
  Transmit Power	CE < 20 dBm (2.4 GHz) < 23 dBm (5 GHz) FCC < 30 dBm
  Wireless Functions	Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
  Wireless Security	64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK encryption




  Software Features
  Quality of Service (QoS)	WMM, Bandwidth Control
  WAN Type	Dynamic IP, Static IP, PPPoE, BigPond, L2TP(Dual Access), PPTP (Dual Access)
  Management	Access control  Local management  Remote management
  DHCP	Server, Client, DHCP Client List, Address Reservation
  Port Forwarding	Virtual Server, Port Triggering, UPnP, DMZ
  Dynamic DNS	DynDns, Comexe, NO-IP
  VPN Pass-through	PPTP, L2TP, IPSec
  Access Control	Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
  Firewall Security	DoS, SPI Firewall  IP Address Filter / MAC Address Filter / Domain Filter  IP and MAC Address Binding
  Protocols	Supports IPv4 and IPv6
  USB Sharing	Support Samba (storage), FTP server, media server, printer server
  Guest Network	1 x 2.4 GHz guest network  1 x 5 GHz guest network




  Environmental Specifications
  Operating Temperature	32 to 104°F / 0 to 40°C
  Storage Temperature	-40 to 158°F / -40 to 70°C
  Operating Humidity	10 to 90% non-condensing
  Storage Humidity	5 to 90% non-condensing




  General
  Certification	CE  FCC  RoHS
  System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista, 7, 8, 8.1, and 10 MAC OS NetWare UNIX or Linux
  Dimensions (WxDxH)	7.2 x 4.9 x 1.3 / 182.95 x 123.5 x 32.1 mm)




  Packaging Info
  Package Weight	1.65 lb
  Box Dimensions (LxWxH)	11.2 x 8.8 x 2.7"







• ㆍWhat is in the box ?

  - Body

  - Adaptor

  - Cable

  - Manual
