产品名称：

            mini pcie PCI-E mSATA转接SATA 2.5"硬盘转接盒7mm外壳          SA-092

产品介绍：

完美支持SATA3传输标准，转接卡仅改变固态硬盘的接口形式，并不改变您的硬盘的任何性能，

您原来硬盘参数是什么，配上转接卡，输出接口性能不会改变。

本款商品外型大小跟7毫米厚度 2.5寸笔记本硬盘一样(超薄7mm移动硬盘，不是9.5mm标准硬盘)

注意：

1：本款商品仅支持mini pci-e里面mSATA接口定义的固态硬盘，mSATA并不等于1.8寸的MICRO SATA，

不支持mini pci-e里面SATA MINI PCIE(华硕信号）接口定义的固态硬盘，用错会烧卡

2：mini pci-e接口的固态硬盘有三种引脚定义，一种是叫mSATA，多见于联想和THINPAD机器上，也可以称之为INTEL定义接口；另一种叫SATA MINI PCI-E，多见于华硕的EPC以及一些平板电脑上；还有一种是PATA定义的，其本质是IDE接口，多见于戴尔MINI 9等机器上。三种接口定义外观完全一样，肉眼无法分辨，所以请务必区分好您的固态硬盘的接口定义！
product name:

            mini pcie PCI-E mSATA adapter SATA 2.5 "hard drive adapter box 7mm shell SA-092



product description:

The perfect support for SATA3 transfer standard, adapter card only changes the form of solid state drive interface, does not change any of your hard disk performance,

What is your original hard drive parameters, coupled with the adapter card, the output interface performance will not change.

The size of this paragraph with 7mm thick 2.5-inch laptop hard drive the same (ultra-thin 7mm mobile hard drive, not a 9.5mm standard hard drive)

note:

1: This product supports only the solid state drive defined by mSATA interface in mini pci-e, mSATA is not equal to 1.8 inch MICRO SATA,

Does not support mini pci-e inside SATA MINI PCIE (ASUS signal) interface definition of solid-state hard drive, the wrong will burn card

2: mini pci-e interface SSD has three pin definitions, one is called mSATA, more common in Lenovo and THINPAD machines, also can be called INTEL definition interface; the other is called SATA MINI PCI-E, and more Found in Asus EPC and some tablet PCs; there is a definition of PATA, its essence is the IDE interface, more common in machines such as Dell MINI 9. The definition of the three interfaces exactly the same, the naked eye can not tell, so be sure to distinguish your SSD definition of the interface!
