Product Description
Product Specification
Processor
CPU: GX6605C
Flash Memory: 4MB(32Mb)
Tunner (RDA5815M)
Tuner: DVB-S/S2
Demodulation: QPSK, 8PSK,16APSK,32APSK
Input Frequency: 950MHz--2150MHz
Input level: -80～-20 dBm
Input impedance: 75Ω
Video
Video Decoding: ISO/IEC 11172-2 MPEG1, ISO/IEC 13818-2 MPEG2 MP@HL; ISO/IEC 14496, MPEG4 Compliant Support SP@l3 to ASP@L5; ISO/IEC 14496-10 AVC high, Profile@level 4.1 Main profile@level 4.1
Video Output: CVBS (video format@576i or 480i) ; HDMI 1.3 (video format default @ Auto, Support HDCP)
Video Resolution: 1080p/i, 720p/i, 576p/i, 480p/i
Audio
Audio Decoding: MPEG1 Layer1/2, MPEGII LayerII
Audio Mode: Mono/Stereo/Left/Right
Screen
Screen Size: 4.3 Inch LCD
Screen Button: USB 2.0 Port for Multimedia Player and Software Upgrade
Panel
ANT IN: Receives the Signal from Satellite Antenna
Panel Button: UP, Down, Left, Right, OK, Exit, Menu, F1-F4; AV-IN/OUT, emulation, Spectrum, Constellation, USB, Power
RS232: RS232 cable for software upgrade
DC Power: EXTERNAL POWER
Speaker
Beep: 8Ω/4Ω; 0.5W 5V
LED lamp: 1W
Indicator: Power, 22K, 13V/18V
Power
DC input Range: 12V/1.5A
Battery Capacity: Built-in 3000Mah rechargeable lithium battery
Accessories: User Manual/Power adapter
