Ancel GX100 Auto InjectorNON-DISMANTLE CLEANER GX100 for Automotive fuel injector tester and cleaner

Fuel System Cleaning GX100 can clean fuel injector・ Air intake system and Three-Way Catalytic Converter・ it is a Free disassembly cleaning tools for GX100 Fuel injector cleaner and tester.

Ancel GX100Fuel System Cleanercan clean gasoline EFI Electronic Fuel InjectionSystem ・ Fuel injector・ Air Intake Throttle System and Three-WayCatalytic Converter・ it is a Free disassembly cleaning tools .

The injector clean kits includes many different kinds of adapter・ cover almost all the EU・Asia・USA cars and light trucks(petrol).

The system is not only characteristic of high and low pressure cleaning function.

At the same time put the function of the whole combustion chamber fuel system of several major functions in one product・ such as cleaning throttle valve and the fuel nozzle.

1. Please make sure start the engine to clean the fuel system. then machine can work.

2. Connect the air source power to the airport of the cleaner・ adjust its pressure 40-50PSI.

3. To the air throttle style system・ the way of connection is the same・ just adjust the pressure of the air source 1-5PSI.

5.Do not includ the cleaner liquid・ please order in your local market if needed

1. Find out the fuel return hose・ disconnect it and plug it with suitable adaptor;
2. Find out the fuel inlet hose・ disconnect it and connect it with the hose of the cleaner with proper adaptor;
3. Connect the and return hose of the fuel tank・ and open the tank cover; if there is not return hose・ please move the fuse
of the fuel pump so that the pump will not work;
4. Charge the cleaning fluid into the tank of the cleaner;
5. Connect the air source power to the air port of the cleaner・ adjust its pressure 40-50PSI;
6. Check all connect point to make sure there is not leakage;
7. Start the engine to clean the fuel system.

The way of connection is the same・ just adjust the pressure of the air source 1-5PSI.
The way to identify the inlet and return hose:
1.Generally speaking・ inlet hose is bigger・ return hose is samaller;
2.There is always a filter connected in the inlet hose side・ and a buffer in the return side;
3.There is arrow on the hose to show the fuel flow direction
NOTE: To the throttle style system・ the way of connection is the same・ just adjust the pressure of the air source 1-5PSI

1.Find out the fuel return hose・ disconnectit and plug it with suitable adaptor
2.Find out the fuel inlet hose・ disconnect itand connect it with the hose of the cleaner with proper adaptor
3.Connect the and return hose of thefuel tank・ and open the tank cover・ if there is not return hose・ please movethe fuse of the fuel pump so that the pump will not work;
4.Charge thecleaning fluid into the tank of the cleaner
5.Connect the air source power to the airport of the cleaner・ adjust its pressure 40-50PSI
6.Check all connect point to make sure there is not leakage
7.Start the engine to clean the fuel system.

Note:To the throttle style system・ the way ofconnection is the same・ just adjust the pressure of the air source 1-5PSI.

The way to identify the inlet and return hose:
1・Generallyspeaking・ inlet hose is bigger・ return hose is samaller
2・There is always a filter connected in theinlet hose side・ and a buffer in the return side
3・There isarrow on the hose to show the fuel flow direction.

4. Wear protective glasses before operation . observe the joint whether there is oil leak. if there is・ please start to work after remove the fault. as a result of losses caused by human negligence・ the user undertakes the responsibility

Ancel GX100 Item work video:

injector: http://v.youku.com/v_show/id_XMTQ0NDA1Nzky.html

Three-Way Catalytic Converter: http://v.youku.com/v_show/id_XMjA0NTIyODQw.html

Air intake system: http://v.youku.com/v_show/id_XMjkzOTE2OTY4.html

FAQ before order:

Q1: Howtochoosea fule injector systemtester?

A1: It isaccuracy. comparedto other tester・ the GX100 function will powerful than another tools.

it including fule intector system・air intake port・catalytic converter test and clean.

Q2: engine need start when GX100 work?

A2: yes friend・ start the engine to clean the fuel system.then machine can work.

Q4: What pressure need change when it work?

A4:Connect the air source power to the airport of the cleaner・ adjust its pressure 40-50PSI.

to the throttle style system・ the way ofconnection is the same・ just adjust the pressure of the air source 1-5PSI.
