Product Description

Each DMX common controller occupied 4 DMX address, adopt coding switch is setting DMX original address code from 1 to 9, 1 is the lowest, and 9 is the highest , 511 address code could be setted in all. This DMX common controller adopts the advanced
micro control unit, receives standard DMX-512 digital control signal and transformed it into PWM signal to driving LED
With over 30 preprogrammed color changing patterns, including gradual changing, screening and jumping, our DMX controller offers a variety of display options.. As a powerful color managing controller, it will enable you to choose the desired pattern and appropriate speed to manage your RGB LED lighting fixtures.With 0 to 100 dimming grades, you can also control the color and brightness according to your requirements easily, and mix up to 1 million different colors.The LCD monitor on the controller offers an easy and visible managing method; the mounting bracket will enable the operator to easily fix the controller onto any place.
>>>Specifications:
-Working temperature: -20 to +60 centigrade
-Output: 4 CMOS drain-open output
-Connecting mode: common anode
-Input Voltage: 12~24V DC -Output Current:<4A(each circuit)
_Output Power:4A -5V:<80W, 12V:<192W, 24V:<384W (4 circuit)
-Static power consumption:<1W
-Product size: L177*W42*H33mm
Net weight:201g
>>>Application: This controller gives any uses full lighting manipulation to meet almost all applications need by allowing users to control all colors, hue, and brightness of the RGB strip light.

Feature

Meets DMX512
256-levels brightness, full-color with driver controls
Can achieve asynchronous color changes effect under working with controller.
With the light color selected mechanism, and be able to control the light with 1~4 colors
Modularizing and can be matched with different LED module neatly
Brand : JOYLAND
Item model num : CECOMINOD044251
MPN(PartNumber) : CECOMINOD044251
EAN : 0709803692879
Product Dimensions(LxWxH) : 4x5x18cm ; 227 g
Package Dimensions(LxWxH) : 19x6x5cm ; 227 g
