Product Description

Specifications:
Material: aluminum alloy, light weight and portable.
Power: AC 100v-240v.
Input: DC 18v.
Output:
--7 way 9v 100ma.
--1 way 9v 500ma.
--1 way 12v 100ma.
--1 way18v 100ma. Dimension: 150 x 50x 30mm.
Net weight: 196g.
Color: black.

Short-circuit protection
All 10 outputs in this unit have separate short-circuit protection, i.e. Short circuit in one channel won't affect other channels' function. Under the circumstances of all LED lights on, LED light of the short-circuited channel will off, while lights in the other normal channels are still on. This helps locating the faults when there were short circuits among many effectors.

Attention:
Incorrect polarity would damage this unit, please make sure correct positive and negative polar before wiring. Package included:
1 x donner dp-1 supply.
1 x power adapter.
10 x DC power cable.
2 x polarity reversal cable.
1 x user manual.

Feature

10 Isolated output, isolated short circuit/overcurrent protected
Material: aluminium alloy, light weight and portable
Bright blue LED for pedal board lighting & short circuit indicate
Includes link power cables (10pcs)
Power: AC 100v-240v input: DC 18v powers for 9v 12v or 18v pedal
Brand : Donner
Item model num : DP-1
MPN(PartNumber) : DP-1
EAN : 0708302975773
Product Dimensions(LxWxH) : 17x16x7cm ; 440 g
Package Dimensions(LxWxH) : 17x16x7cm ; 440 g
