Product Description

Main Features:
1. Complies with IEEE 802.11b/g/n standards
2. Supports Router,Client,Bridge,Repeater,AP mode
3. QoS function assures the quality of VoIP and multimedia streaming
4. Wireless N speed up to 300Mbps and Backward compatible with 802.11b/g/n products
5. Compact and portable,powerful wireless signal as well
6. Travel size design,ideal for home or travel use
7. Support WEB,WPA/WPA2,WPA-PSK/WPA2-PSK encryptions

NOTE:
Choose a location away from Bluttooth devices and other household electronics, such as cordless phone,microwave,and baby monitor,etc.,to minimize signal interference

Package Contents:
Before you starting to use this router, please check if there's anything missing in the package,and contact us to claim for missing items
1* Wireless N mini Router
1* Quick Installation Guide
1* RJ-45 Networking Cable

Hardware Parameter:
Port: 2* 10/100M LAN
Antenna: 2* PCB inside Antennas
Button:Reset button, WPS fast encryption button
Indicator light:
POWER light is on indicating the power supply is in normal;
LAN/WLAN light is on indicating connection,light flashing indicating transfering or receiving;

Wireless Parameter:
Wireless standards: IEEE 802.11b/g/n
Frequency:2.412-2.484 GHz
Wireless Rate: transfer/receive rate: 300M
Transmit power:<20dBm
Receiving sensitivity:-68dBm@10%--90dBm@10%
Encryptions:64/128/152-bit WEP/WPA/WPA2,WPA-PSK/WPA2-PSK

Software Parameter:
Login IP :192.168.10.253
Login name/code: admin/admin
Default mode: AP
DHCP:Service-Client mode

POWER:
Input voltage VAC: 110-230 V
Output voltage VDC: 5V==1A
Temperature:
Working temperature: 0-40℃
Storage temperature:-30--70℃

Humidity:
Working/Storage humidity 10%-90% RH without condensation

Feature

300Mbps HIGH-SPEED SEAMLESS WIFI COVERAGE: With 2 external high gain rotated dual antennas, the wifi extender booster signals go through 2 walls, to solve the wifi signal weakly coverage in duplex apartments, large-sized housings, villas, it's easy to eliminate the signal dead points and solve the home networking congested problems while many networking equipment connecting the wifi, Stronger signals, faster speed experience, you can enjoy the wonderful internet world
A PUSH OF WPS BUTTON, EASY TO COMPATIBLE WITH MAINSTREAM ROUTERS: Press the repeater and router within 2 minutes of the WPS button, you can complete the pairing connection between repeater and router, it's compatible with top brand routers on sale,like netgear,tplink, linksys, ect
MULTI-MODE USING SCENES: REPEATER mode, the house has a wireless router already, but the wifi signal is weak or hard to find in the bedroom, then you need this wifi amplifier to expand wifi signals range , booster wifi signal enhancer; WIRELESS ACCESS POINT mode, at home, office or hotel, you can provide the wireless signal after the wifi extender connect the router via wired RJ45 cable; ROUTER mode: simply connect the wired network, itself can creat wifi networking when set router mode
SMALL TRAVEL SIZE DESIGN: Independent power switch to control the power on or off yourself, dual ethernet network ports wall plug design, nonoccupying household space, easy and portable to carry on travel
1 YEAR GUARANTEE,45 DAYS MONEY BACK: Ideal for extending wifi signal to devices iPhone, Samsung Galaxy, iPad, PS 4, Fire Tablets, and other Smart Home Devices, NOTE You can reset your WiFi Router to default setting by press and hold the RESET button for 8-10 seconds, you can use this solution if you forget your password, Protective film of the surface layer can be torn off. If you want help, please feel free to contact us，we'll provide friendly easy-to-reach customer service support
Brand : Dekyda
MPN(PartNumber) : wifi extender-black
EAN : 0799460239524
Product Dimensions(LxWxH) : 10x6x5cm ; 204 g
Package Dimensions(LxWxH) : 14x12x10cm ; 204 g
