Product Features:

2 main chip: REALTEK RTL8188EUS / ETV

2 Supported protocols and standards: IEEE 802.11g， IEEE 802.11b， IEEE 802.11n

2 Interface Type: USB1.1 USB2.0

2 Frequency range: 2.4-2.4835GHZ

2 working channels: 14

2 data modulation: OFDM / CCK / 16-QAM / 64-QAM

2 mode of operation: centralized control (Infrastructure)， the equation (Ad-Hoc)

2 Transmission rate: 150Mbps (maximum) t

2 Spread Spectrum Technology: DSSS (Direct Sequence Spread Spectrum)

2Measure: PER: 135M: -72dBm @ 10% PER; 130M: -72dBm @ 10% PER; 108M: -72dBm @ 10% PER; 54M: 6M: -88dBm @ 10% PER; 1M: -90dBm @ 8% PER

2 RF Power: 15dbm (max)

2 antenna: 2dBi built-in smart antenna

2 transmission distance: depending on the environment

2 Supported Operating Systems: Windows XP / VISTA / WIN7 / WIN 8 / MAC / LINUX

2 Operating voltage: DC 5V + -0.2V

2 LED indication: Status

2 Size: 20 * 15 * 6mm



Use of the environment: Operating temperature: 0 ℃ ~ 40 ℃

Storage temperature: -40 ℃ ~ 70 ℃

Operating humidity: 10% to 90% RH non-condensing

Storage humidity: 5% to 90% RH non-condensing

应用范围

2      台式电脑

2      智能电视机

2      机顶盒

2      媒体播放器

2      笔记本
