Product Description

NOTE:

work with Android APP and Android Phone & Android Tablet

Support the Apple APP and iPhone.

Camera Parameter:
Image Sensors: IR Color CCD Camera
Wireless camera built in802.11VIDEO Transmitter
Transmission: 100m open air
TV System:NTSC
Waterproof rate:Ip67
Effective Pixels:684 x 512pixels
Resolution:540TV lines
Minimum Illumination:0.5Lux / F1.2 0.2Lux / F1.2 (0Lux IR ON)
Pin Lens:f=2.8mm / F = 2.0
Lens Angle:120°
IR leds: 28 Pcs
Vertical Sync. Frequency:50Hz / 60Hz
Video Output:1.0vp-p, 75Ohm
Power Supply:DC12V-24V
Current Consumption:≤300mA
Electronic Shutter:1/60 ~ 1/10,000 Seconds
Gamma Consumption:0.45
S/N Ratio:Better than 48Db
Scanning System:2:1Interlace
Operating Temperature:-20°C~70°C ,RH95％ MAX
Storage Temperature:-40°C~85°C ,RH95％ MA
Power (Max.) supply: DC12-32V

How to use :
1,Download & install APP
In order to facilitate customers to use, currently IRearCam. Apk are placed in the SDK.
Store path：SNCC60_SDK_V1.0/SNCC60_SDK/Download
Same with all the Android APP installation way.

2,Get password & set APP
In order to make the use safe, each SNCC60 has its own security code, It can automatic access password.

Package:

1 x Wifi Camera
1 x User Manual Inluded

Feature

The new mode of transmission, combined with the reality, realize the real intelligence revresing.
The android with WiFi devices, can realize the wireless rear view
Avoid wiring, realize wireless reversing, save the complex installation program and installation cost
WiFi wireless transmission, pure digital models without interference, Receiver completely without any external equipment, installation is more convenient, suitable for all kind of vehicles
Use the most advanced h. 264 video coding technology,image clear and fluent.
Brand : iPerfect
MPN(PartNumber) : WFC-011
EAN : 0713179803852
