Product Description

Specifications:
Type: AC/DC power supply
Input Voltage: 115-240V 50/60Hz
Output Voltage: DC12V
Wattage: 120W
Output Current: 10A
Output Voltage Accuracy: ± 2
Output Ripple Noise: 50 mv
Working Efficiency: 80-85%
Protection: Shortage Protection, Overload Protection, Over Voltage Protection
Certification: CCC & CE
Working Condition: 0~45℃

Application:
MR16/MR11/G4 LED spotlight lamps
LED strips
Retrofit low voltage LED lighting
Wireless Router
Security Cameras
Audio/Video Power Supply

Connection:
L, N: AC power input
GND: DC power output "-"
V: DC power output "+"
+V/ADJ: Adjust the output voltage
Safety Compliance: CCC/ FCC/CE
Working Temperature: 0~40℃
Storage Temperature: -20~60℃
Ambient Humidity: 0~95% Non-Condensation

Package Included:
1pc 10A Switching Power Supply

Feature

Universal AC input / full range. It's good quality and high performance.
Protections: overload/ over voltage/ short circuit protection.
100% full load burn-in test. Cooling by free air convection.
With anti-jamming to ensures the long life LED lamps and reduce the LED luminous decay.
Applications: 5050 3528 5630 LED Strip Light.
Brand : DC HOUSE
MPN(PartNumber) : L09KGDY10A-1
EAN : 0799442590117
