Product Description

Description
Chipset: RTL8188
Item model: W87B
Wireless Standards: IEEE 802.11n、 IEEE 802.11g、IEEE 802.11b、CSMA/CA with ACK

Frequency Range: 2.4～2.4835GHz

Peak Throughput: 150Mbps

Modulation Type: 802.11 g/n: OFDM 802.11b: CCK(11, 5.5Mbps), QPSK(2Mbps), BPSK(1Mbps)

Work Mode: Infrastructure Ad-Hoc
Transmission Mode: DSSS

Channel: 1-14
Wireless Security: 64/128-bit WEP, WPA, WPA2 Please note:only win 7 win 8 support bluetooth,for Windows 2000/XP/Vista/WIN CE support wireless don't support bluetooth
Support Operating System: Windows 2000/XP/Vista/WIN 7/WIN CE/LINUX
Receiving sensitivity ：130M： -65dBm@10% PER; 108M：-65dBm@10% PER; 54M：-65dBm@10% PER; 11M：-87dBm@8% PER; 6M：-90dBm@10% PER; 1M：-90dBm@8% PER
Interface: USB 2.0
Transmission distance:50 meters in the indoor, outdoor as far as 150 metres (due to the different environment) Transmission rate :802.11 b: 11 ", 2, 1 Mbps 802.11 g:,48,36,24,18,12,9,6 54 Mbps 802011 n: up to 150 MBPS Working current 100 ma - 200 ma, + WIFI (BT) (current change with working mode)
Antenna Gain: 3.5Dbi
RF Output Power: 16dBm（max）

Dimensions: 13 * 12.2 *2mm
Package included: 1x 150 Mbps USB Bluetooth 4.0 wifi adapter 1XCD

Feature

Wireless Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Data rates: up to 150 Mbps, Plug and Play USB2.0 interface with Bluetooth 4.0
MIMO technology improves effective throughput and range over existing 802.11 b/g products
Please note:only win 7 win 8 support bluetooth,for Windows 2000/XP/Vista/WIN CE support wireless don't support bluetooth
please note there are two drive one is for wifi adapter another is bluetooth,you must install both drive and then can use it.
Brand : Dragon
Item model num : W87B
MPN(PartNumber) : W87B
EAN : 0600316588263
