Hantek 6074BE Automotive Diagnosis Equipment, Car Diagnostic Oscilloscope, Automobile Diagnostic Instrument, Automobile Special Oscilloscope, with 4CH 70MHz 1GSa/s
[Product Information]
- Fit for the portable computers, table PC, and suitable for wild mobile use and business trip use. Support WIN10/ WIN8/WIN7 etc. USB 2.0 interface plug and play, and no need extra power supply.
- Great function, More than 20 kinds of automatic measurement function, PASS/FAIL Check function. Resourceful trigger function, dynamic cursor tracking, waveform record and replay function.
- Good mechanical design with small size which is easy for carrying. The outer case is made by the same material with iPad - Anodised aluminium. It has great heat resistance and abrasive resistance with beautiful appearance. The hardness of aluminium alloy surface is greatly improved.
- 4 isolated channels oscilloscope, 1GSa/s real time sampling rate, 2mV-10V/DIV high input sensitivity and large input range, 70MHz high bandwidth. The waveform data could be output to EXCEL,BMP,JPG.
- Waveform averaging, afterglow, lightness control, reverse, add, subtract, multiply, divide, X-Y display. FFT spectrum analyzer. One computer could connect with multiple oscilloscopes, expand the channel number easily. Provide secondary development library DLL; Provide LabviewVBVCQT developing examples.
