3D printer Technical Specifications:
1.Frame | Aluminium+ Threaded rod |
2.Print size ( X Y Z ) | 200 x 200 x 180mm |
3.Z Axis Positioning Accuracy | 0.004mm |
4.XY Axis Positioning Accuracy | 0.012mm |
5.The Layer Thickness | 0.1 mm-0.4mm |
6.Layer Resolution | 100 microns |
7.Printing Filament | PLA, ABS, Wood |
8.Favored Filament | PLA |
9.Filament Diameter | 1.75mm |
10.Nozzle Diameter | 0.4 mm(customized 0.3mm/0.5mm) |
11.Print Speed | 40 - 100 mm/s |
12.Print Plate Size | 200mmx200mm |
13.Print Plate (Build Platform) | Heated bed ( Aluminium Platform) |
14.Max heated bed temperature | About 110 deg C(adjustable) |
15.Max extruder temperature | About 240 deg C |
16.No. of Extruders | One |
17.LCD included | Yes |
18.Connectivity (Interface) | USB, LCD display and SD card reader |
19.Electronics | MKS Gen-2Z v1.1 (Ramps Compatible ) |
20.Power supply | Input: 100-120VAC/4.8A or 200-240VAC/2.4A |
21.Output | DC 12V/ 30A |
22.3D printing Control Software | Repetier-Host |
23.CAD Input data file format | STL, G-code |
24.Operating System | Windows/ XP/ Mac |
25.Machine Size | 430*505*380mm |
26.Package Size | 520*470*240mm |
27.Machine weight | 8kg |
28.Package Weight | 13.5kg |
29.Environmental requirement | Temp: -5 - 40°c,Humidity:20-70% |
30.Warranty | 12 Months |
3D Printer easy to assemble:
The 3D printer mechanical part can be finished between 3-5 hours depending on your experience with RepRap 3D printer machines.
Note: Parts and components for DIY, you have get a chance to assemble a 3D printer of your own now!
3D printer package included:
FREE All assembly units.
FREE All assembly tools. (Allen key, Wrench, Twizer, etc)
FREE All assembly datasheet (Document, Picture, Video)
FREE Software.
FREE Usb cable.
FREE 8G SD Card (Stand alone printing)
FREE LCD
FREE 2 Roll PLA filament (net weight 1kg/roll, 350 meters)
FREE 2 Roll PLA filament (net weight 100g/roll, 30 meters )
Specifications:
Nozzle Diameter: 0.4mm (customized 0.3mm/0.5mm)
Resolution: XY axis 100 steps/mm, Z axis 5 steps/mm, Extruder 50 steps/mm
Build volume: 200mm x 200mm x 200mm
Machine dimension (L*W*H*): 430* 450* 300mm
Print surface: Aluminium/Glass
Printing speed: 40 ~ 100 mm/s
Nozzle quantity: Single
SD Card Print: Support
LED screen: Yes (with 2004LCD display)
Machine weight: 8kg
Package weight : 13.5kg
Support date type: STL,G-Code
Voltage input: 240V
Voltage output: 12V
Gross power: 250W
Plug cable: 3 pin
Fused Filament Fabrication (FFF) using 1.75mm PLA or ABS filament
