LCD TV: 2010 C550 and above 2011 D530 and above

LED TV: 2010 C5000 and above 2011 D5000~D64**2012 EH 4500, EH 5300, EH 5400, ES 5500,ES 5700

PDP TV: 2010 C550 and above (C540 is only supported in North America)2011 D550~D64**2012 E 490, 550(Korea, Europe & CIS)

BD Player: 2010 C5*** series 2011 D53**~D55** 2012 BD E5500

HES: 2010 C5*** series 2011 D51**~D53** (D5000~D55**, D7000 is only supported in Europ)2012 E4200, 4500

Music, Photo Play

Music, Photo Play IEEE 802.11a/b/g/n Recommended

Wireless Standards

Wireless Standards IEEE 802.11a/b/g/n Application

Frequency Range

Frequency Range: 2.412~2.4835GHz / 5.15~5.850GHz

weight

Products(g) 17g

including packaging(g) 103g

Accessories

User Manual

AV gender

USB Extension

SD Video Streaming

SD Video Streaming IEEE 802.11a/b/g/n Recommended

Sensitivity

IEEE802.11a/g Sensitivity: -68dBm at 54Mbps

IEEE802.11b Sensitivity: -84dBm at 11Mbps

IEEE802.11n Sensitivity: -68dBm (20MHz) / -65dBm (40MHz)

Power Consumption

Power Consumption TX: 500mA

Power Consumption RX: 300mA

Size

Set (W x H x L) (mm) : 26.6 x 84 x 16 mm

Package (W x H x L) : 95 x 165 x 30 mm

HD Video Streaming

HD Video Streaming IEEE 802.11a/b/g/n(2.4GHz) Negative

HD Video Streaming IEEE 802.11n (5GHz) Recommended

Data transfer rate

IEEE802.11a/g Data transfer rate: 54, 48, 36, 24, 18, 12, 9 and 6Mbps

IEEE802.11b Data transfer rate: 11, 5.5, 2 and 1 Mbps

IEEE802.11n Data transfer rate: Max 300Mbps (40MHz / spatial streams:2)

Security

Security: 64/128bit WEP, WPA /WPA2, 802 1x, WPS

Output Power

IEEE 802.11a External output: 11dBm at 54Mbps

IEEE 802.11b External output: 17dBm at 11, 5.5, 2, and 1Mbps

IEEE 802.11g External output: 14dBm at 54 Mbps

IEEE802.11n(2.4GHz) External output: 14dBm (20MHz) / 12dBm (40MHz)

IEEE802.11n(5GHz) External output: 11dBm (20MHz) / 9dBm (40MHz)

Host Interface

Host Interface USB 2.0
