Product Description

Supplier: Dixon®
Material: 316 Stainless Steel
Seal: Buna-N
Size: 2"
Maximum Operating Pressure: 250 PSI
Weight (lb): 6.625
Applications: Designed for use with liquids, consult Dixon for specific recommendations
Specifications: Produced to interchange with all product produced to Commercial Item Description A-A-59326D
Construction: Produced as a welded fabrication
How it works: To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.; Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
Safety notes: Under no circumstances should cam and groove couplings be used for compressed air or steam service!; Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70?F (21?C) with a standard seal installed. For use a
