可以安装1个 M2 PCIe(67pin M key) SSD硬盘到 台式机电脑、工作站或者服务器的PCIex4 插槽。

支持三星950PRO、SM951、XP941、浦科特M6E等型号M.2 SSD。，是台式机电脑、工作站与服务器安装固态硬盘的一种经济实惠的解决方案。

产品特性

• 可安装1个 M2 PCIe(67pin M key) SSD固态硬盘到 PCIe 3.0 ×4插槽；

• 支持 M2 PCIe Gen3 与 PCIe Gen2 SSD 固态硬盘，长度42, 60 与 80 mm，支持三星950PRO、SM951、XP941、浦科特M6E等型号。；

• 支持 PCIe 1.0, 2.0 与3.0 插槽；

• 最高传输速度取决于 M2 PCIe SSD固态硬盘与您电脑主板的PCI-E插槽规格，为了获取最佳传输性能，建议为这个卡选择一个PCI-E 3.0的插槽；

• 可安装于标准高度插槽或者低挡板插槽，标配包括高低两种挡板；

• 在台式机电脑、工作站、服务器中，用速度更快、功耗更低、防震性更好的M2 PCIe SSD固态硬盘取代传统的机械硬盘

• M2 PCIe SSD固态硬盘可用于安装操作系统与应用软件(需要主板芯片组与BIOS支持)

• 运行温度: -40 °C to + 85 °C

• 支持各种操作系统，不需要安装驱动程序

  温馨提示： M2 PCIe(67pin M key) SSD不同于 M2 SATA （(67pin B key)）SSD，这款产品仅支持M2 PCIe SSD

• You can install one M2 PCIe (67pin M key) SSD drive to the PCIex4 slot on your desktop computer, workstation, or server.

  Support Samsung 950PRO, SM951, XP941, Plextor M6E and other models M.2 SSD. , Is an economical solution for installing SSDs on desktop PCs, workstations and servers.

  Product Features



  Can install one M2 PCIe (67pin M key) SSD solid state drive to PCIe 3.0 × 4 slot;

  Support M2 PCIe Gen3 and PCIe Gen2 SSD solid state drives, length 42, 60 and 80 mm, support Samsung 950PRO, SM951, XP941, Plextor M6E and other models. ;

  Support PCIe 1.0, 2.0 and 3.0 slots;

  The maximum transfer speed depends on the M2 PCIe SSD SSD and the PCI-E slot specification of your computer motherboard. For best transfer performance, we recommend you choose a PCI-E 3.0 slot for this card.

  Can be installed in the standard height slot or low baffle slot, the standard includes two kinds of baffles;

  In desktop computers, workstations, servers, with faster, lower power, better shockproof M2 PCIe SSD solid state drive to replace the traditional mechanical hard drive

  M2 PCIe SSD SSDs for operating system and application installation (requires motherboard chipset and BIOS support)

  Operating temperature: -40 ° C to + 85 ° C

  Support various operating systems, do not need to install the driver


  Tips: M2 PCIe (67pin M key) SSD is different from M2 SATA (67pin B key) SSD, this product only supports M2 PCIe SSD
